13
Use two M8 x 16 mm SBHCS screws to attach the right frame leg to the underside of the
remaining table section. Tighten with the 5 mm Allen wrench.
M8 x 16 mm
SBHCS (x2)
Table Section
Right Frame
Leg
Carefully lift the table to a standing position.
5
6
Building the Frame Table (Continued)
Full Frame Assembly
7
Attach one of the corner braces to the top right corner of the frame with the 5 mm Allen
wrench and four M8 x16 mm SBHCS screws.
M8 x 16 mm
SBHCS (x4)
Corner Brace
Note: Keep table and leg as square as possible while attaching brace.
To Next Page
