Installation
14 332305J
Alarm Output and Remote Illumination Response
The following tables include graphical representations of the connector as it appears on the unit, a pin-out associated
with the connector and a typical installation wiring diagram. An internal representative wiring diagram is included
where it is deemed useful.
Wire colors provided on these pages only refer to the power cable provided by Graco with this product.
Outputs (“08” option) (via 5 wire CPC)
*Firmware 6.04 and above for non-DMS models and 7.07 and above for DMS models. For A11 OFF the Alarm Pin 4 activates ON
during a warning. It is shown with A11 ON.
Alarm Output
(via DIN alarm relay
connector)
Standard Remote
Illumination
(via 5 wire CPC power
cable)
Tri-Color Remote
Illumination
(via M12 Connector)
Unit in OFF Mode Deactivated (off) Off Off
Unit in ON Mode Deactivated (off) On Green
Warning Condition (A11
OFF)
Activated (on)
Toggles On and Off once
per second
Yellow
Low Level Indication (A9
OFF)
See Warning or Fault Con-
dition
Toggles On and Off once
per second
See Warning or Fault Con-
dition
Fault Condition
(Advanced Programming
A7 OFF)
Toggles On and Off once
per second
Toggles On and Off once
per second
Red
Fault Condition (Advanced
Programming A7 ON)
Activated (on)
Toggles On and Off once
per second
Red
Pin 4
Alarm
Pin 7
Low Level
Low Level Warning
FIRMWARE 6.02 and above
(A7 OFF, A9 ON)
Off*
Toggles On and Off once
per second
Low Level Warning
(A7 OFF, A9 OFF)
Off* Activated (On)
Low Level Fault
(A7 OFF, A9 OFF)
Toggles On and Off once
per second
Activated (On)
Low Level Fault
(A7 ON, A9 OFF)
Activated (On) Activated (On)
