Installation
332305J 15
Alarm Relay Response
Wiring and Installation Diagrams
The following Table identifies the wiring and installation diagrams provided in this manual.
Output Tied to Common
No Faults or
Warnings
Warning
(Advanced
Programming
Setting A11 OFF)
Fault
(Advanced
Programming A7
OFF)
Fault
(Advanced
Programming
Setting A7 ON)
N.O.
N.C.
N.O.
N.C.
N.O.
N.C.
1 second
N.O.
N.C.
Diagram Symbol Page #
Power DIN AC 16
Power DIN DC 16
Power CPC DC 17
Inputs (M12)
18
Vent Valve Outputs 19
Alarm Outputs 19
Illuminated Manual Run Input
Kits: 571030, 571031,
571032, 571033
