Graco G3 Series User Manual

Parts
84 332305J
Fuses
Installation and Repair Kits
Part Description Qty
571039 FUSE, 12 volt DC
1
571040 FUSE, 24 volt DC
1
Kit No. Description
Manual
Number
571026 KIT, output union, 3 pump
3A0523
571063 KIT, output union, 2 pump
571028
KIT, return to reservoir NPT, includes pres-
sure relief valve 16C807
3A0525
571071
KIT, return to reservoir BSPP, includes pres-
sure relief valve 16C807
571030 KIT, remote manual run, 12 volt DC
3A0528
571031 KIT, remote manual run, 24 volt DC
571032
KIT, remote manual run, 12 volt DC, with
cable
571033
KIT, remote manual run, 24 volt DC with
cable
571036 KIT, cover with “G” label NA
571041 KIT, pump element, includes Ref 17, 18, 33 3A0533
571042
KIT, repair, 2 liter reservoir, includes Ref 13,
36, 40
3A0534
571069
KIT, repair, 2 liter reservoir, for models with
follower plate, includes Ref 13, 36, 40
571044
KIT, replacement, paddle, 2 liter, for models
without follower plate, includes Ref 13, 16,
35, 57
3A0535
571045
KIT, replacement, paddle, 2 liter, for models
with follower plate, includes Ref 13, 16,
35,40a, 42, 57
571046
KIT, replacement, paddle, 4-16 liter, for mod-
els without follower plate, includes Ref 13,
16, 35, 57
571047
KIT, replacement, paddle, 4 liter, for models
with follower plate, includes Ref 13, 16, 35,
57
571058 KIT, output adapter, NPT
3A0522
571070 KIT, output, adapter, BSPP
571060 KIT, fill, zerk, leak proof NA
571179
KIT, repair, reservoir oil, 2 liter models,
includes Ref 13, 36, 40b
3A0534571182
KIT, repair, reservoir, oil 4 liter models,
includes Ref 13, 36, 40b
571183
KIT, repair, reservoir, grease, 4 liter models,
includes Ref 13, 36, 40b
127685 RING, fixing for CPC connector NA
16G02
2
CAP, filler 1
