Table 5: Color Change Board Diagnostics
LED
Connector
and Pin Nos.
Board 1 Signal
Description
Board 2 Signal
Description Diagnosis
D8 n/a Board OK Board OK Blinks (heartbeat) during normal operation.
D9 n/a Communication
(yellow)
Communication
(yellow)
Turns on when board is communicating with Pro-
Mix 2KS.
D10 J7 Power Power Turns on when power is supplied to the board.
D27 J15, 5 & 6 Color 3 Color 16
D27 through D46 turn on when ProMix 2KS sends
a signal to actuate the related solenoid valve.
D28 J14, 3 & 4 Color 1 Color 14
D29 J8, 5 & 6 Color 6 Color 19
D30 J14, 1 & 2 Color 2 Color 15
D31 J8, 3 & 4 Color 7 Color 20
D32 J16, 3 & 4 Catalyst 4 Color 26
D33 J8, 1 & 2 Color 8 Color 21
D34 J9, 5 & 6 Color 9 Color 22
D35 J15, 3 & 4 Color 4 Color 17
D36 J14, 5 & 6 Solvent (Color) Color 13
D37 J10, 5 & 6 Catalyst 2 Color 28
D38 J16, 1 & 2 Catalyst 3 Color 27
D39 J16, 5 & 6 Color 12 Color 25
D41 J15, 1 & 2 Color 5 Color 18
D43 J9, 3 & 4 Color 10 Color 23
D44 J9, 1 & 2 Color 11 Color 24
D45 J10, 3 & 4 Catalyst 1 Color 29
D46 J10, 1 & 2 Solvent (Catalyst) Color 30
F1 Replaceable
Fuse
n/a n/a Check fuse condition if there is no power to the
board or if communication is interrupted between
the fluid station and the color change module.
