Graco ProMix 2KS Repair Manual

Parts
312780K 69
277869 EasyKey, with Display
 Replacement Danger and Warning labels, tags, and
cards are available at no cost.
Parts labeled n/a are not available separately.
Available Cables
Ref.
No. Part No. Description Qty
201 n/a CONTROL BOX, with display 1
202 116320 SWITCH, power 1
203 n/a LATCH; includes item 3a 1
203a 117818 • KEY 1
204 111987 CONNECTOR, cord strain
relief
1
205 110911 NUT, hex; M5 x 0.8 4
206 111307 WASHER, lock, external tooth;
M5
9
207 n/a HOLDER, tie 8
208 C19293 NUT, hex 6
209 194337 WIRE, grounding, door 1
210 15X779 KIT, display, interface; includes
items 210a, 210b, 210d, and
210e; does not include 210c
1
210a n/a • MEMBRANE 1
210b n/a • GRAPHIC, display 1
210c 255767 • BOARD, EasyKey display
(not part of kit)
1
210d n/a • PLATE 1
210e n/a • SCREW; 4-40 x 1 in. (25
mm)
4
211 15D568 ALARM 1
212 15W776 LABEL, warning 1
213 223547 GROUND WIRE; 25 ft (7.6 m) 1
214 n/a PLATE, application; includes
items 214a-214m
1
214a 255786 • BOARD, barrier, IS;
(includes fuses 15D979 and
114788, see page 45 for fuse
location)
1
214b n/a • COVER 1
214c 117526 • SPACER 3
214d 119257 • BAR, ground 1
214e 114095 • BLOCK, terminal 1
214f 121314 • POWER SUPPLY; 24 Vdc;
2A
1
214g n/a • SCREW, machine, pan-hd;
6-32 x 3/8 in. (10 mm)
3
214h n/a • SCREW, machine, pan-hd;
6-32 x 1-1/2 in. (38 mm)
2
214j n/a • SCREW, machine, pan-hd;
8-32 x 3/4 in. (19 mm)
2
214k n/a • SCREW, machine, pan-hd;
10-24 x 3/8 in. (10 mm)
11
214l 123823 • FILTER, line, single-phase;
110/250 V; 3 A
1
214m 123824 • BRACKET, line filter 1
215 15V280 HARNESS, connection 1
216 15G569 LABEL, EasyKey inputs 1
218 15R642 HARNESS, wire 1
220 n/a SOFTWARE, application 1
221 198165 CONNECTOR, RJ45, with
bulkhead fitting
1
223 116343 SCREW, ground; M5 x 0.8 1
224 15G869 CABLE, ethernet, CAT5; 6 ft
(1.8 m); to make web interface
connection to a computer
1
CAN Cables
Part No.
Length
ft (m) Usage
15U531 2 (0.61) Option
15U532 3 (0.92) Standard color change
15V205 6 (1.83) Option
15V206 10 (3.05) Option
15V207 15 (4.57) Option
15V208 25 (7.62) Option
15U533 50 (15.25) Standard power
15V213 100 (30.50) Option
Fiber Optic Cables
Part No. Length Usage
15D320 50 (15.25) Standard
15G710 100 (30.50) Option
Ref.
No. Part No. Description Qty
