Graco ProMix 2KS Repair Manual

Parts
312780K 63
Part No. AD000N to AD742Y and AE100N, includes EasyKey with LCD display
Ref.
No.
Configured Digit
(see page 61) or
part usage
Part No. Description Qty
2
D 277869 CONTROL/DISPLAY, EasyKey; used on AD000N to AD742Y;
see page 68
1
3
standard part see page 70 PANEL, fluid 1
4
standard part 289695 MANIFOLD, mix; see manual 312781 1
standard part 24Y548 ACID MANIFOLD, mix; see manual 312781 1
8
KIT, flow meter A
0 none none 0
1 15V804 KIT, G3000 flow meter; see manual 308778 1
2 15V827 KIT, G3000HR flow meter; see manual 308778 1
3 15V806 KIT, Coriolis flow meter; see manual 313599 1
4 15V804 KIT, G3000 flow meter; see manual 308778 1
5 15V806 KIT, Coriolis flow meter; see manual 313599 1
6 15V827 KIT, G3000HR flow meter; see manual 308778 1
7 15V806 KIT, Coriolis flow meter; see manual 313599 1
9
KIT, flow meter B
0 none none 0
1 15V804 KIT, G3000 flow meter; see manual 308778 1
2 15V827 KIT, G3000HR flow meter; see manual 308778 1
3 15V804 KIT, G3000 flow meter; see manual 308778 1
4 15V806 KIT, Coriolis flow meter; see manual 313599 1
5 15V827 KIT, G3000HR flow meter; see manual 308778 1
6 15V806 KIT, Coriolis flow meter; see manual 313599 1
7 15V806 KIT, Coriolis flow meter; see manual 313599 1
8 17L432 KIT, G3000A acid meter; see manual 308778 1
10
0 - 4 see page 79 MODULE, control, color/catalyst change; see page 79 see page 79
-- see page 79 ACID MODULE, control, color/catalyst change; see page 79 see page 79
11
0 - 4 see page 79 VALVE STACK, color change; see page 79 see page 79
-- see page 79 ACID VALVE STACK, color change; see page 79 see page 79
12
0 - 2 see page 79 VALVE STACK, catalyst change; see page 79 see page 79
-- see page 79 ACID VALVE STACK, catalyst change; see page 79 see page 79
14
FLOW CONTROL
N none none 0
Y 249849 REGULATOR, flow control 1
15
used with flow
control only
15U977 CABLE, flow control; connects flow control regulator to fluid
station; 40 ft (12.2 m)
0 or 1
16
used with color
change only
15U532 CABLE, CAN, intrinsically safe; connects color change control
module to fluid station; 3 ft (1 m)
0 or 1
17
used with AE100N
only
826212 KIT, G3000A flow meter, see manual 308778 1
26
standard part 15V256 KIT, automatic upgrade; includes item 26a 1
26a
standard part 15V825 • KIT, board, discrete I/O; part of item 26 1
