Graco Reactor 2 H-XP3 Repair Manual

Repair
Replace Replace
Replace
Belt Belt
Belt
1.FollowShutdown,page49.
2.Removetheheatercover(134)andthebelt
coverfasteners(19).
NOTICE NOTICE
NOTICE
Topreventdamagetotheovertemperature
switch,carefullyremovethecovers.
3.Liftcover(132)andloosenthebluebracket(131)
fasteners.Liftthebluebracket(133)offofthe
fastenersandsetaside.Removethebeltcovers
(131,132).
4.Removethebelt.
5.Installthenewbeltandreplacethecovers.
56 334946C
