Installation
5.InsertandtightentheTSLbottlemounting
bracketscrewstosecurethebracketinthe
uprightposition.
Mount Mount
Mount
the the
the
System System
System
Topreventseriousinjuryduetothesystem
tippingover,ensurethattheReactoris
properlysecuredtothewall.
NOTE: NOTE:
NOTE:
Mountingbracketsandboltsareincluded
intheboxofloosepartsshippedwiththe
system.
1.Securetheleftandrightwallmounting
brackets(MB)tothewall.Ifthebracketsdo
notlineupwiththewallstudspacing,bolta
pieceofwoodtothestudsthensecurethe
bracketstothewood.
2.Usethefourholesinthebaseofthesystem
frame(BH)tosecurethebasetotheoor.
Theboltsarenotsupplied.
BH
22
3A8500A
