Graco Reactor E-10hp - DIP Switch Settings and Functions

Troubleshooting
332144E 31
DIP Switch Settings and Functions
* Default DIP Switch Settings
DIP Switch Settings and Functions
DIP Switch and Function OFF ON
DIP Switch 1
If selected, displays a status code or displays a status code
and causes shutdown if the pressure imbalance exceeds
selection made in DIP Switch 2.
DEVIATION DEVIATION AND
SHUTDOWN
DIP Switch 2
Select pressure imbalance limits, that if exceeded, will cause
a deviation and a shutdown (if enabled).
See Dip Switch 1 and 2 Settings table, page
31
DIP Switch 3
If selected, causes shutdown or displays a status code due
to deviation of pressure from setpoint exceeds selection
made in DIP Switch 4.
DEVIATION
*SHUTDOWN
DIP Switch 4
Causes deviation if pressure setpoint is greater than:
300 psi (2.1 MPa, 21
bar)
(25% if < 800 psi [5.6
MPa, 56 bar])
*500 psi (3.5 MPa, 35
bar)
(40% if < 800 psi [5.6
MPa, 56 bar])
DIP Switch 5
Causes shutdown or displays a status code for low fluid level
in tanks.
*DEVIATION
SHUTDOWN
DIP Switch 6
Enables or disables boost heat.
DISABLE
*ENABLE
DIP Switch 7
Not used
DIP Switch 8
Not used
DIP Switch 1 and 2 Settings
DIP
Switch 1
DIP
Switch 2
Deviation Shutdown
Off Off
300 psi (2.1
MPa, 21 bar)
---
Off
*On
500 psi (3.5
MPa, 35 bar)
---
*On
Off
300 psi (2.1
MPa, 21 bar)
500 psi (3.5
MPa, 35 bar)
*On *On
500 psi (3.5
MPa, 35 bar)
800 psi (5.6
MPa, 56 bar)
