Graco SlimFit3 LX User Manual

5-C
Forward-Facing with LATCH
64
8. Connect the Lower Anchor Connectors to
Vehicle’s Lower Anchors
Make sure the arrows are pointing up.
Lower anchor strap should not be twisted.
If twisted, you will not be able to tighten the
strap.
Lower anchor connectors can only be used
if the vehicle lower anchor spacing is 11
inches (28 cm) from the center of one lower
anchor to the center of the other lower
anchor.
CLICK!
11” (28 cm)
NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 64NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 64 9/18/20 11:49 AM9/18/20 11:49 AM

Graco SlimFit3 LX Specifications

General

Product Type	3-in-1 Car Seat
Rear-Facing Weight Capacity	5-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Booster Mode Weight Range	40-100 lbs
Height Capacity	Up to 57 inches
Harness Type	5-point harness
Harness Positions	10
Side Impact Protection	Yes
Cup Holders	2
Machine Washable Cover	Yes
Weight Capacity	5-100 lbs
Installation	LATCH
Recline Positions	4
