Graco SlimFit3 LX User Manual

Moving Lower Anchor Attachment
8
93
2. Unsnap Upper Seat Pad to Expose the Lower
Anchor Attachment
3. Remove Lower Anchor Attachment from
Storage Location
Lift seat pad and remove lower anchor
connectors from storage location. First, push on
the tab on the seat in front of the lower anchor
connector (A) and then pull on the lower anchor
strap to remove the lower anchor connector (B).
Repeat on the other side.
4. Slide Entire Lower Anchor Strap Along Bar to
the Desired Belt Path Openings
Rear-Facing: Slide Lower Anchor Strap along bar
to the front of the seat.
Forward-Facing: Slide the Lower Anchor Strap up
along bar to the top.
A
B
NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 93NWL0001077519C SlimFit3 LX USA ENG R04 (8BZ20.indd 93 9/18/20 11:50 AM9/18/20 11:50 AM

Graco SlimFit3 LX Specifications

General

Product Type	3-in-1 Car Seat
Rear-Facing Weight Capacity	5-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Booster Mode Weight Range	40-100 lbs
Height Capacity	Up to 57 inches
Harness Type	5-point harness
Harness Positions	10
Side Impact Protection	Yes
Cup Holders	2
Machine Washable Cover	Yes
Weight Capacity	5-100 lbs
Installation	LATCH
Recline Positions	4
