WP810 Administration Guide
Version 1.0.7.83
WP810 WEB GUI SETTINGS
This section describes the options in the WP810 Web UI. As mentioned, you can log in as an administrator
or an end user.
 Status: Display account status, network status and system info.
 Accounts: Configure accounts with general settings, SIP settings, codec settings, call settings and
advanced settings.
 Settings: Configure general settings, call settings, ringtone, Video Settings, Multicast paging
 Network: Wi-Fi settings, and advanced network settings.
 Maintenance: Configure upgrade and provisioning settings and system diagnosis.
 Directory: Configure phonebook settings and Call History
Status Page Definitions
Status/Account Status
Account
Displays list of configured accounts.
SIP user ID
Displays the numbers of the configured accounts.
SIP Server
Displays list of SIP Server user by the configured accounts.
SIP Registration
Shows the status of SIP registration. If the SIP account is successfully registered,
it will display “Registered” with green background. If the SIP account is not
registered, it will display “Unregistered” with grey background.
Status/Network Status
MAC Address
Shows Device ID in hexadecimal format. This is needed by network administrators
for troubleshooting. The MAC address will be used for provisioning and can be
found on the label on original box and on the label located on the bottom panel of
the device.
IPv4 Address Mode
Indicates the configured address mode: DHCP or Static IP
IPv4 Address
Displays assigned IP address. Example: 192.168.5.110
Subnet Mask
Displays assigned subnet mask. Example: 255.255.255.0
Gateway
Displays assigned default gateway. Example: 192.168.5.1
