29
The wires on the ghost® saddles must go into the control cavity
to plug into the Hexpander or into the Acousti-Phonic via the
Summing Board and Dual Connector Cable. Cutting six, small
notches beneath the bridge-side of the pick guard or pickup ring
lets the wires enter an existing cavity neatly and without modifying
the body. Notches can be cut with a Dremel-type rotary tool or by
hand with a needle le. Remove the pick guard or pickup ring from
the instrument body for this operation. We recommend removing
the pickup from the pickup ring to prevent damaging the pickup.
Saddles
Notching the pick guard or pickup ring
Notched
Pick Guard
Notched
Pickup Ring
To Next Page
