Graphtech Ghost User Manual

30
Slotting the base plate of the bridge is an alternative to notching
the pick guard or pickup ring. It will make the Ghost® wires
practically invisible by running them into the guitar body through
slots cut in the bridge. The bridge will have to be removed from the
guitar and taken to a machine shop that can cut the slots precisely
in the steel. The diagram below shows the slot dimensions.
Slotting the base plate *optional*
0.240”
0.080”
0.160”
equal to your string spacing
