68
This kit is for connecting the ghost® pickups to an output jack
without the Acousti-Phonic. It provides an on-board acoustic
volume control, and prevents loss of high frequencies at
lower volumes. The 2M volume pot included in the kit helps
match the resistance of the ghost pickups to a standard
amp input. Without the Acousti-Phonic, the output of the
pickups is rather harsh, and does not sound like an acoustic
guitar, so we recommend that you process the passive
signal external to the guitar using a preamp or active EQ.
Passive volume kit
SIGNAL
GROUND
Ring
Sleeve
1M
Tip
SIGNAL
GROUND
2M
330pF
