63
the black ground wires on the harnesses. These ground wires
will all be lifted from the battery negative when the 1/4” plug
is removed from the Stereo Switched Jack, powering o both
the Acousti-Phonic and the active pickups or other accessory.
Plug in the battery harness last, and make absolutely
certain that the black wire is alone on the ground
row of pins, and the two red wires are on the
row with the other colored wires. Plugging this
in incorrectly may damage the ghost® boards.
The battery harness connector spans the two pin
rows labeled PWR (power) and BAT (battery).
Connecting battery to Acousti-Phonic
To Next Page
