GRASS VALLEY Trinix User Manual

Installation
118 Planning and Installation Manual
Table 19 shows the switches providing adjustment relative to SR-33500
Reference 3.
Table 19. Switch point shift for signals referenced to Ref 3.
The switches that provide adjustment relative to SR-33500 Reference 4
are shown in Table 20.
Table 20. Switch point shift for signals referenced to Ref 4.
+2.0 line On Off Off
+2.5 line Off Off Off
Switch point relative to Ref.
3
SR-33500: S102-1 SR-33500: S102-2 SR-33500: S102-3
-1.0 line On On On
-0.5 line Off On On
Coincident (default) On Off On
+0.5 line Off Off On
+1.0 line OnOnOff
+1.5 line Off On Off
+2.0 line On Off Off
+2.5 line Off Off Off
Switch point relative to Ref.
4
SR-33500: S102-4 SR-33500: S102-5 SR-33500: S102-6
-1.0 line On On On
-0.5 line Off On On
Coincident (default) On Off On
+0.5 line Off Off On
+1.0 line OnOnOff
+1.5 line Off On Off
+2.0 line On Off Off
+2.5 line Off Off Off
