Planning and Installation Manual 171
• “Reclocker” (DV-33512) - “L” = monitor output board is locked
to (and is reclocking) the signal. “B” = monitor output board is
bypassing (and not reclocking) this signal For more information
about output monitor reclocking, see page 142.
For more information about output monitoring, refer to the manual
supplied with the control system.
Note The Monitor display has not been fully defined for expanded systems.
Selecting the Input tab will display a menu similar to that shown in
Figure 99. This table shows the following for each input:
• Input signal presence (yes or no)
• Whether or not the input is in use (i.e., whether or not it is cur-
rently switched to an output).
• If a proper input signal was present but has since been lost
Figure 99.
