4-002 Description of the Individual Assembly Groups
Electrical Switch Box of Ecopress-Pneumatic Illustration 4-002-05
1 Lead cable 5 x 1.5 mm
2
2Thermal excess current release
3 Electric safety feature (fuse) for control circuit; reserve fuse in switch box cover
4 Power contactor switches the motor on
5 Cable to the electric motor
6 P-E-transformer switches on the power contactor and, therewith, the motor
7 Adjusting screw to set the operating speed. The more the adjusting screwed in turned
inwardly, the slower the operating speed
8 One-way restrictor valve
9 One-way restrictor valve
10 Adjusting screw to set the after-running time of the electric motor;
Warning: This screw must not be adjusted.
Electrical Switch Box of Ecopress-Manual Illustration 4-002-06
1 Lead cable 5 x 1.5 mm
2
2Thermal excess current release
3 Electric safety feature (fuse) for control circuit, reserve fuse in switch box cover
4 Power contactor switches the motor on
5 Cable to the electric motor
6 Cable to the roller limit switch, see Position 7
7 Roller limit switch turns on the power contactor and , therewith, the motor
