7. Operating the Ecopress 34-65
7-3 Adjusting the Ecopress 40-49
7-301 Adjusting the boring depth 40-41
7-302 Adjusting the boring distance 40-41
7-303 Adjusting the boring speed of the Ecopress-Pneumatic 42-43
7-304 Adjusting the turn-on time of the E-Motor with the Ecopress-Pneumatic 42-43
7-305 Adjusting the turn-on time of the E-Motor with the Ecopress-Manual 44-45
7-306 Adjusting the side stops 44-45
7-307 Operating the stop adjustment gauge 46-47
7-308 Operating the index ruler ( accessory) 48-49
7-309 Adjusting the hold down clamps ( accessory ) 48-49
7-4 Examples of Usage 50-65
7-401 Drilling and inserting the Grass Hinge System 1000/3000/4000 50-51
7-402 Drilling and inserting the Grass Baseplate System 1000/3000 52-53
7-403 Drilling the hole line borings ( only with accessories ) 54-55
7-404 Drilling the fronts for Grass Zarge System 6000/7000 56-57
7-405 Drilling the back panels for Grass Zarge System 6000/7000
( only with accessories ) 58-59
7-406 Drilling and inserting visible hinges 60-61
7-407 Drilling and inserting fastening hardware 62-63
7-408 Drilling of handle bore holes ( only with accessories ) 64-65
8. Trouble Shooting and Problem Solving 66-69
8-001 Incorrect boring distance - adjustment of scale 66-67
8-002 Boring speed cannot be adjusted 67
8-003 Motor does not run 67
8-004 Boring head does not descend 69
8-005 Parts do not fit the drill patterns when inserted 68-69
9. Maintenance and Care 70
9-001 Maintenance plan 70
9-002 Maintenance and care information 70
10. Miscellaneous 71-80
10-001 Guarantee certificate 71-72
10-002 Disposal form 73-74
10-003 Resale form 75-76
10-004 Questionnaire 1 77-78
10-005 Questionnaire 2 79-80
10-006 List of Grass distributors 81
