Dedicated TUNE mode will always check for the presence of encoded
squelch modulation each time it finds an active frequency. If a valid
encoded squelch code is found, it will be shown on the display, and stored
automatically when you press
STOR
to create a new CONV object.
Dedicated TUNE mode also displays information about trunking control
channels and trunked voice channels it finds while tuning through the RF
spectrum. The following information is displayed for the various trunking
modes:
Trunked Mode Analysis Display
M o t o r o l a 3 6 0 0
b a u d c o n t r o l
channel
qq% SID:ssss Stt
where qq=decoding quality of the control channel
data, SID=System ID, and S=Site Number
E D A C S c o n t r o l
channel
qq% S:ss h/H s/S a/A
where qq=decoding quality of the control channel
data, S=Site ID, h/H=not home site/is home site, s/
S=not SCAT site/is SCAT site, a/A=not Aux CC/is
Aux CC
LTR home repeater
HR:hh A-HH-GGG
where HR=the home repeater number of the tuned
frequency, A-HH-GGG=the Area, Home Repeater
and Group ID of the LTR talkgroup
Motorola analog
voice channel
VC: lsTGID-nnnnn
where lsTGID shows the decoded talkgroup ID data
from the lowspeed data stream
Please note that the analog lowspeed data protocol
does not provide error correction, and some false
“
VC: lsTGID
” readings should be expected.
You may wish to use the PSR-410's Tune LED feature to obtain a visual
indication of signal strength using the tri-color LED. To activate the Tune
LED, press PROG, then the
GLOB
softkey. Press the
6
key until Tune
LED: Off
appears in the display. Use the
34
keys to toggle Tune
LED on or off, then press the
SAVE
softkey to save your changes to the
radio's configuration memory.
