855 Smart Bender™
Special Bending Information Chart (cont’d)
1" EMT
Y 15 1.35 9.07 16.80 24.53 32.26 39.98 51.58 63.17 86.35 132.71
L1 15 7.72 15.44 23.17 30.90 38.63 46.35 57.94 69.54 92.72 139.08
L2 15 9.60 17.33 25.06 32.79 40.51 48.24 59.83 71.42 94.61 140.97
Z 15 12.55 20.02 27.48 34.94 42.41 49.87 61.07 72.27 94.66 139.44
MINIMUM H = 1.32
Y 22.5 4.31 9.54 14.77 19.99 25.22 33.06 40.90 56.58 87.93
L1 22.5 10.42 15.64 20.87 26.09 31.32 39.16 47.00 62.68 94.04
L2 22.5 13.25 18.47 23.70 28.93 34.15 41.99 49.83 65.51 96.87
Z 22.5 15.72 20.54 25.37 30.20 35.03 42.27 49.51 64.00 92.97
MINIMUM H = 2.32
Y 30 1.72 5.72 9.72 13.72 17.72 23.72 29.72 41.72 65.72
L1 30 7.91 11.91 15.91 19.91 23.91 29.91 35.91 47.91 71.91
L2 30 11.69 15.69 19.69 23.69 27.69 33.69 39.69 51.69 75.69
Z 30 13.98 17.45 20.91 24.37 27.84 33.03 38.23 48.62 69.41
MINIMUM H = 3.53
Y 45 4.32 7.15 9.97 14.22 18.46 26.94 43.91
L1 45 11.00 13.83 16.66 20.90 25.15 33.63 50.60
L2 45 16.67 19.49 22.32 26.57 30.81 39.29 56.26
Z 45 17.16 19.16 21.16 24.16 27.16 33.16 45.16
MINIMUM H = 6.48
Y 60 3.52 5.83 9.30 12.76 19.69 33.55
L1 60 10.77 13.08 16.55 20.01 26.94 40.79
L2 60 18.32 20.63 24.10 27.56 34.49 48.34
Z 60 17.29 18.44 20.18 21.91 25.37 32.30
MINIMUM H = 9.97
Y90 7.02 13.02 25.02
L1 90 14.91 20.91 32.91
L2 90 26.23 32.23 44.23
Z90 17.61 17.61 17.61
MINIMUM H = 17.61
1-1/4" EMT
Y 15 7.41 15.13 22.86 30.59 38.31 49.91 61.50 84.68 130.04
L1 15 7.71 15.44 23.17 30.90 38.62 46.35 57.94 69.53 92.72 139.08
L2 15 10.09 17.82 25.55 33.27 41.00 48.73 60.32 71.91 95.09 141.46
Z 15 13.79 21.26 28.72 36.18 43.65 51.11 62.31 73.50 95.90 140.68
MINIMUM H = 1.65
Y 22.5 2.74 7.96 13.19 18.42 23.64 31.48 39.32 55.00 86.36
L1 22.5 10.41 15.63 20.86 26.08 31.31 39.15 46.99 62.67 94.03
L2 22.5 13.97 19.20 24.42 29.65 34.88 42.72 50.56 66.23 97.59
Z 22.5 17.21 22.03 26.86 31.69 36.52 43.76 51.01 65.49 94.46
MINIMUM H = 2.89
Y 30 4.12 8.12 12.12 16.12 22.12 28.12 40.12 64.12
L1 30 11.89 15.89 19.89 23.89 29.89 35.89 47.89 71.89
L2 30 16.64 20.64 24.64 28.64 34.64 40.64 52.64 76.64
Z 30 19.20 22.66 26.12 29.59 34.78 39.98 50.37 71.16
MINIMUM H = 4.40
Y 45 2.55 5.38 8.20 12.45 16.69 25.18 42.15
L1 45 13.75 16.58 20.82 25.07 33.55 50.52
L2 45 20.88 23.71 27.95 32.20 40.68 57.65
Z 45 21.46 23.46 26.46 29.46 35.46 47.46
MINIMUM H = 8.10
Y 60 1.50 3.81 7.27 10.73 17.66 31.52
L1 60 16.34 19.81 26.74 40.59
L2 60 25.85 29.32 36.25 50.10
Z 60 23.08 24.81 28.28 35.21
MINIMUM H = 12.49
Y 90 1.23 4.23 10.23 22.23
L1 90 20.10 32.10
L2 90 34.37 46.37
Z90 22.10 22.10
MINIMUM H = 22.10
DIM ANGLE 2" 4" 6" 8" 10" 12" 15" 18" 24" 36"
