855 Smart Bender™
Main Parts List (cont’d)
UPC No.
Key 78-3310- Part No. Description Qty.
UPC No.
Key 78-3310- Part No. Description Qty.
97 50224 905 0224.8 Screw, 5/16-18 x 1.00 Skt Hd ............. 1
98 50881 905 0881.5 Screw, 1/4-28 x .25 Set ...................... 2
99 53018 905 3918.4 Washer, 1.00 x 1.37 x .03 Shim ......... 1
100 54248 905 4248.7 Washer, Belleville 1.362 x .803 .......... 2
101 39440 503 9440.1 Washer, .62 x 2.00 x .06 Flat ............. 1
104 54243 905 4243.6 Spring, Extension .75 x 3.50 .............. 2
105 54252 905 4252.5 Clamp, Loop Type............................... 1
106 52108 905 2108.0 Nut, Hex 1/4-20 ................................... 1
107 54239 905 4239.8 Screw, 1/4-20 x 3/4 Ovl Pt Set ........... 1
108 39851 503 9851.2 Cam, Retention ................................... 1
109 38463 503 8463.5 Shaft, Cam Retention ......................... 1
111 38544 503 8544.5 Plate, Cam Retention.......................... 1
112 38566 503 8566.6 Spring, Cam Retention ....................... 1
113 54268 905 4268.1 Screw, 1/4-20 x 1-3/8 Skt Cap ........... 1
114 50458 905 0458.5 Rollpin, 1/8 x .375 ............................... 1
115 38592 503 8592.5 Guide, Spring ...................................... 1
116 51130 905 1130.1 O-Ring, 1.50 x 1.62 x .062.................. 2
117 51537 905 1537.4 O-Ring, 1.75 x 1.87 x .062.................. 2
118 38657 503 8657.3 Shaft, 2 Middle Roller ......................... 1
119 52644 905 2644.9 Washer, 1/32 Shim ............................. 1
150 52645 905 2645.7 Washer, 1/16 Shim ............................. 1
151 53216 905 3216.3 Retaining Ring .................................... 1
170 86263 918 6263.9 Nut, 1/2" Conduit Lock ........................ 1
176 54911 905 4911.2 Screw, 1/4-28 x 3/8" Skt. Hd. Cap...... 2
201 38141 503 8141.5 Base Weldment, Trunnion .................. 1
202 38157 503 8157.1 Tower Weldment, L.H. Trunnion ........ 1
203 38161 503 8161.0 Tower Weldment, R.H. Trunnion ........ 1
204 53390 905 3390.9 Wheel .................................................. 2
205 38166 503 8166.0 Axle, Long ........................................... 1
206 51528 905 1528.5 Ring, Retaining #5160-75 ................... 2
207 54237 905 4237.1 Screw, Flange 3/8-16 x 1.00 Hx ....... 16
208 52646 905 2646.5 Nut, 3/8-16 Esna Hex ......................... 4
209 38167 503 8167.9 Pin, Trunnion Lock .............................. 1
211 54244 905 4244.4 Spring, Trunnion Lock......................... 1
212 38168 503 8168.7 Knob .................................................... 1
213 38464 503 8464.3 Pad Weldment, Jack Bolt ................... 4
215 54276 905 4276.2 Caster, Swivel ..................................... 2
220 38156 503 8156.3 Block, Reinforcement.......................... 2
221 31710 503 1710.5 1/2" to 1-1/4" IMC, Rigid Hook ........... 1
223 31712 503 1712.1 1/2" to 1-1/4" EMT Hook ..................... 1
224 52479 905 2479.9 Drive Bolt, 1/2-13 x .62
Socket Head Cap Screw..................... 6
225 51088 905 1088.7 1/2" to 1-1/4" Hook Bolts,
3/8-16 x 1-1/4 Socket Head
Cap Screw........................................... 8
226 53396 905 3396.8 1-1/2, 2" Hook Shoulder Bolts,
3/4 x 1-1/2 ........................................... 6
228 31716 503 1716.4 1-1/2, 2" EMT Hook ............................ 1
229 38779 503 8779.0 1-1/2, 2" IMC & Rigid Hook ................ 1
231 01084 500 1084.0 Selector Switch Unit w/o Knobs ......... 1
232 54880 905 4880.9 Wrench, 5/16" Hex T-handle .............. 1
Decals (not shown)
38893 503 8893.2 Decal, Lifting Eye ................................ 1
38894 503 8894.0 Decal, Kickstand ................................. 1
01445 500 1445.5 Decal, Deluxe Pendant Instr. .............. 1
38896 503 8896.7 Decal, Slct Switch Size ....................... 1
01487 500 1487.0 Decal, Slct Switch Type ...................... 1
38898 503 8898.3 Decal, Bender Pivot Lock ................... 1
38899 503 8899.1 Decal, Roller Adjustment .................... 1
02263 500 2263.6 Decal, Roller Engagement .................. 1
01568 500 1568.0 Decal, Operation ................................. 3
38974 503 8974.2 Decal, Circuit Breaker ......................... 1
01453 500 1453.6 Decal, Shoe Orientation ..................... 2
07248 500 7248.6 Decal, Extension Cord ........................ 1
999 3576.7 Decal, Technical Assistance............... 1
Optional
216 38743 503 8743.0 Stand, Anti-Movement ........................ 1
217 31732 503 1732.6 Pin, Pivot ............................................. 1
218 50881 905 0881.5 Screw, 1/4-28 x .250 Skt Set .............. 1
230 54297 905 4297.5 Spring .................................................. 1
01711 500 1711.0 Deluxe Pendant Control
38962 503 8962.9 Vinyl Cover (not shown)
01700 500 1700.4 1/2" to 2" PVC Shoe Group
Service Only
05586 500 5586.0 Frame Unit (includes bearings) .......... 1
500 7939.5 Cam Repair Kit .................................... 1
233
