Greenlee 855 - Input;Output Board Parts List

Greenlee Textron / Subsidiary of Textron Inc.
53
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
855 Smart Bender™
Input/Output Board Parts List
Serial Numbers ABT0000 through ABT1199
Reference Part Number Description Manufacturer
U1, 12 74HC86N IC
U2 74HC373 IC
U3 93LC56 EEPROM Microchip only
U4 9186832.7 EPROM, Programmed - 855M2
U5 SRAM-32Kx8; 35nS MAX.
U6 ULN2068B Quad Driver
U7 N80C196KB Microcontroller Intel only
U9 HC4066 IC
U10 DS1232 Watchdog IC Dallas Semi
U11 74HC74 IC
SW1 7101-SYCQE SPST Toggle Switch C&K or equal
SW2 8121-SHCGE SPST/No Push MOM Switch C&K or equal
C1,2 RPE110COG220J050V Capacitor 22pF Murata or equal
C3-8,10-24, 29, 30, 32, 34, 35 RPE121X7R104K050V Capacitor, Decouple .1uF Murata or equal
C9, 31, 33 CEUSM1E100 Capacitor 10uF/25V Marcon or equal
C25, 26 158X474 Capacitor .47uF/250V Mallory
C27, 28 CEUSM1E102 Capacitor 1000uF/25V Marcon or equal
F1 313.250 Fuse .250A/250V Littlefuse
102071 Fuse Clip Littlefuse or equal
VR1 MC7812CT Voltage Reg. 12V NAT./MOT. or equal
VR2 MC7805CT Voltage Reg. 5V NAT./MOT. or equal
274-2AB VR Heat Sink/Hardware Wakefield or equal
X1 10 MHZ XTAL HC-18
L1-12 521-9216 LED, RED T1 Dialight or equal
L13 HL8146AB Inductor Hurricane Labs
J1, 7, 9 39-28-1043 Connector, Minifit JR. 4 Molex
J2, 3, 5, 8 39-28-1063 Connector, Minifit JR. 6 Molex
J4, 6 39-28-1023 Connector, Minifit JR. 2 Molex
P1 10-89-1103 Connector, Dual Row Molex
D2, 3, 6-13 IN4001 Diode
R1-6,10-15, 18,19, 23,
25, 26, 29, 49, 50 Resistor 10K 1/4W 5%CF
R7, 30, 31, 36, 42 Resistor 2.2K 1/4W 5%CF
R8, 9, 20, 22, 35, 38, 39 Resistor 1K 1/4W 5%CF
R16, 40, 41, 44-47 Resistor 100 OHM 1/4W 5%CF
R32, 43 Resistor 68 OHM 1/4W 5%CF
R28, 37 Resistor 330 OHM 1/4W 5%CF
R17, 24 Resistor 560 OHM 1/4W 5%CF
R34 MDP1603-102G Resistor Pack Dip 1K Dale or equal
R21, 33 4610X-101-103 Resistor Pack Sip 10K Bourns or equal
R48 V150LA20A Varistor
