Greenlee Textron / Subsidiary of Textron Inc.
27
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
855 Smart Bender™
Special Bending Information Chart (cont’d)
1-1/2" IMC, Rigid and 40 Mil PVC-Coated Rigid
Y 15 5.30 13.03 20.75 28.48 36.21 47.80 59.39 82.57 128.94
L1 15 7.71 15.44 23.17 30.90 38.62 46.35 57.94 69.53 92.72 139.08
L2 15 9.94 17.67 25.39 33.12 40.85 48.58 60.17 71.76 94.94 141.31
Z 15 15.09 22.56 30.02 37.49 44.95 52.41 63.61 74.81 97.20 141.98
MINIMUM H = 1.97
Y 22.5 .90 6.13 11.36 16.58 21.81 29.65 37.49 53.17 84.52
L1 22.5 10.41 15.64 20.86 26.09 31.31 39.15 46.99 62.67 94.03
L2 22.5 13.75 18.97 24.20 29.43 34.65 42.49 50.33 66.01 97.37
Z 22.5 18.44 23.27 28.09 32.92 37.75 44.89 52.24 66.72 95.69
MINIMUM H = 3.36
Y 30 2.44 6.44 10.44 14.44 20.44 26.44 38.44 62.44
L1 30 11.90 15.90 19.90 23.90 29.90 35.90 47.90 71.90
L2 30 16.35 20.35 24.35 28.35 34.35 40.35 52.35 76.35
Z 30 20.35 23.82 27.28 30.75 35.94 41.14 51.53 72.32
MINIMUM H = 4.98
Y 45 1.06 3.88 6.71 10.96 15.20 23.68 40.65
L1 45 13.78 16.60 20.85 25.09 33.58 50.55
L2 45 20.50 23.33 27.57 31.81 40.30 57.27
Z 45 22.47 24.47 27.47 30.47 36.47 48.47
MINIMUM H = 8.82
Y 60 2.45 5.91 9.38 16.30 30.16
L1 60 16.41 19.87 26.80 40.66
L2 60 25.36 28.83 35.76 49.61
Z 60 23.92 25.65 29.12 36.04
MINIMUM H = 13.21
Y90 3.12 9.12 21.12
L1 90 20.33 32.33
L2 90 33.77 45.77
Z90 22.50 22.50
MINIMUM H = 22.50
2" IMC, Rigid and 40 Mil PVC-Coated Rigid
Y 15 4.15 11.87 19.60 27.33 35.06 46.65 58.24 81.42 127.78
L1 15 15.44 23.17 30.90 38.62 46.35 57.94 69.53 92.71 139.08
L2 15 17.80 25.62 33.35 41.08 48.80 60.40 71.99 95.17 141.53
Z 15 22.90 30.36 37.82 45.29 52.75 63.95 75.15 97.54 142.32
MINIMUM H = 2.06
Y 22.5 5.22 10.45 15.67 20.90 28.74 36.58 52.26 83.61
L1 22.5 10.40 15.63 20.86 26.08 31.31 39.15 46.99 62.67 94.02
L2 22.5 14.09 19.31 24.54 29.76 35.00 42.83 50.67 66.35 97.71
Z 22.5 18.89 23.71 28.54 33.37 38.20 45.44 52.69 67.17 96.14
MINIMUM H = 3.53
Y 30 1.62 5.62 9.62 13.62 19.62 25.62 37.62 61.62
L1 30 11.88 15.88 19.88 23.88 29.88 35.88 47.88 71.88
L2 30 16.79 20.79 24.79 28.79 34.79 40.79 52.79 76.79
Z 30 20.92 24.38 27.84 31.31 36.50 41.70 52.09 72.88
MINIMUM H = 5.26
Y 45 .26 3.08 5.91 10.16 14.40 22.88 39.85
L1 45 13.74 16.56 20.81 25.05 33.53 50.50
L2 45 21.10 23.93 28.17 32.42 40.80 57.87
Z 45 23.27 25.27 28.27 31.27 37.27 49.27
MINIMUM H = 9.38
Y 60 1.58 5.04 8.50 15.43 29.29
L1 60 16.30 19.77 26.70 40.55
L2 60 26.13 29.59 36.52 50.38
Z 60 24.99 26.72 30.18 37.11
MINIMUM H = 14.14
Y90 1.94 7.94 19.94
L1 90 31.98
L2 90 46.70
Z90 24.25
MINIMUM H = 24.25
DIM ANGLE 2" 4" 6" 8" 10" 12" 15" 18" 24" 36"
