855 Smart Bender™
Power Generation Unit Parts List
Greenlee No. Location Description Value Manufacturer Part No.
– R1-R2 Resistor 4.7 KΩ / 1/4 w / 5% – –
– R3, R5, R6, R8,
R11, R12 Resistor 10 KΩ / 1/4 w / 5% – –
– R4 Resistor 22 Ω / 1/4 w / 5% – –
– R7 Resistor 68 KΩ / 1/4 w / 5% – –
– R9 Resistor .04 Ω / 5 w / 1% Dale LVR-5 .04Ω
– R13 Resistor 330 Ω / 1/4 w / 5% – –
– R14 Resistor 4.7 KΩ / 10 w / 5% Dale CW-10 4.7K
– R10, 21 Resistor 680 Ω / 1/4 w / 5% – –
– R15-R18, R20 Varistor V15 0 LA 20A GE V150 LA20A
– R19 Resistor 20kΩ / 2w / 1% Dale RS-2B-20K
918 6687.1 D1 Diode – Semikron SKR2F17
– D2, D6 Zener Diode IN4744-DO-41 Motorola IN 4744
– D3, D4 Diode IN914 Motorola IN 914
– D7 Diode IN 4007 Motorola IN 4007
– C1, C2 Capacitor 1mf / 50v Philips CY-30 C105M
– C3 Capacitor 10mf / 250 VAC American 10mf / 20VAC
– C4 Capacitor 330mf / 25v Nichicon 1E331MPA
918 6862.9 C5 Capacitor 1000mf / 250v Nichicon LLR2D
918 6688.0 K1 Relay T81H5D312-05 P & B T81H5D312-05
918 6645.6 Off Board Relay PRD-11DYO-12 P & B PRD-11DYU-12
– L1, L2 Inductor HL-8196 Hurricane HL-8196
– DSI LED LED T1-3/4 Green HP HLMP-3507
918 6690.1 U1 IC 4049 Motorola MC14049UBCP
918 6691.0 U2 OPTO-Isolator GN136N HP HCP4502
918 6692.8 U3, U4 IC LM393 Motorola LM393AN
918 5997.2 Off Board Rectifier GBPC3504 GI GBPC3504
918 6861.0 Q2 Mosfet IXFH40N30 IXYS IXFH40N30
– D1 Heat Sink – Wakefield 695-1
503 8270.5 Off Board Heat Sink – Greenlee –
– J1 Connector – Beau 72503
– J2 Connector Mini-Fit Jr. Molex 39-28-1063-P
– J3, J7 Connector Mini-Fit Jr. Molex 39-28-1023-P
– J4 Connector – Beau 72502
– J5, J6 Connector Mini-Fit Jr. Molex 39-01-2020-P
918 6693.6 T1 Transistor 2N3904 Motorola 2N3904
