Greenlee 855 - Main Parts List

Greenlee Textron / Subsidiary of Textron Inc.
46
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
855 Smart Bender™
UPC No.
Key 78-3310- Part No. Description Qty.
UPC No.
Key 78-3310- Part No. Description Qty.
Main Parts List
2 01622 500 1622.9 Frame Weldment ................................ 1
3 38217 503 8217.9 Guard Weldment, Top Chain .............. 1
4 38983 503 8983.1 Guard Assembly, Front Chain ............ 1
4A 38236 503 8236.5 Guard, Front ........................................ 1
4B 38244 503 8244.6 Retainer............................................... 1
4C 50160 905 0160.8 Rivet, 3/16" Pop .................................. 2
5 38232 503 8232.2 Guard Weldment, Motor ..................... 1
6 01607 500 1607.5 Guard, Bottom ..................................... 1
7 38199 503 8199.7 Sppt Wldt, 1/2" to 1-1/4" RLR ............. 1
8 38250 503 8250.0 Drive Unit ............................................ 1
9 01702 500 1702.0 Spindle Weldment, Main ..................... 1
10 38193 503 8193.8 Plate Weldment, Drive ........................ 1
11 54253 905 4253.3 Sprocket, #60 14T .............................. 1
12 38267 503 8267.5 Key, Drive Sprocket ............................ 1
13 54255 905 4255.0 Bearing, Sleeve #48DU40 .................. 2
14 54250 905 4250.9 Chain, #60 92P ................................... 1
15 54462 905 4462.5 Ring, Rtng Truarc #5100-200 ............. 4
16 38265 503 8265.9 Washer, Main Spindle......................... 2
17 38268 503 8268.3 Key, Shoe Drive .................................. 1
18 38457 503 8457.0 Plate, Hoist .......................................... 2
19 55204 905 5204.0 Pin, 1/2" to 1-1/4" Sprt Pvt .................. 1
20 38257 503 8257.8 Spacer, Motor Mount .......................... 1
20A 39488 503 9488.6 Spacer, Thin Motor Mount .................. 1
21 38228 503 8228.4 Locator Weldment, Eccentric.............. 1
22 54265 905 4256.8 Nut, 1/2-13 Lock.................................. 1
23 51655 905 1655.9 Screw, #10-16 x .50 Hex Hd............. 31
25 53903 905 3903.6 Screw, Cap 1/2-13 x 1.00 ................... 4
26 52501 905 2501.9 Ring, Rtng Truarc #5100-287 ............. 2
27 54345 905 4345.9 Screw, Set 1/2"-20 x .75 Socket ......... 1
28 54251 905 4251.7 Link, Connecting #60 Chain ............... 1
29 54240 905 4240.9 Screw, #6-32 x 1.00 Sltd Mch ............ 4
30 38246 503 8246.2 Bracket, Limit Switch .......................... 1
31 38248 503 8248.9 Back-Plate, Switch .............................. 2
32 50226 905 0226.4 Screw, 5/16-18 x 1.25 Sk. Cap........... 2
33 52597 905 2597.3 Washer, Flat .56 x 1.37 x .109 ........... 4
34 85822 918 5822.4 Switch, Limit #BZ-2RW822-A2 ........... 2
35 50645 905 0645.6 Nut, Hex 5/16-18 Reg Jam ................. 2
36 01708 500 1708.0 Receptacle Unit, Pendant ................... 1
37 54124 905 4124.3 Strain Relief ........................................ 1
38 38546 503 8546.1 Cover, Switch ...................................... 1
39 38638 503 8638.7 Switch Unit, Unload Lckt ..................... 1
40 54313 905 4313.0 Screw, Mach #2-56 x .75 .................... 2
41 54314 905 4314.9 Nut, Lock #2-56 Hex ........................... 2
42 50763 905 0763.0 Screw, Mach #8-32 x .25 .................... 2
43 38780 503 8780.4 Shoe Unit, 1/2" to 1-1/4" ..................... 1
44 38148 503 8148.2 Shoe Unit, 1-1/2" to 2" ........................ 1
45 52203 905 2203.6 Screw, Mach #6-32 x .25 .................... 2
46 29708 502 9708.2 Guard, Breaker Switch........................ 1
47 86385 918 6385.6 Breaker, Circuit 20 Amp ..................... 1
48 54619 905 4619.9 Screw, CAP #4-40 x .62 Skt ............... 2
49 38646 503 8646.8 Encoder Unit, Optical .......................... 1
50 50572 905 0572.7 Screw, Cap #8-32 x .50 Skt ................ 4
51 86646 918 6646.4 Brake, Motor ....................................... 1
52 38807 503 8807.0 Key, Brake........................................... 1
53 54616 905 4616.4 Spacer, Round Plastic ........................ 2
54 54151 905 4151.0 Knob, Plastic w/Set Screw.................. 2
55 54335 905 4335.1 Screw, Flng 1/4 x .37 Thd................... 2
57 01648 500 1648.2 Switch, Pendant .................................. 1
57A 01305 500 1305.0 Board, Circuit ...................................... 1
57B 33476 503 3476.0 Cover ................................................... 1
57C 33472 503 3472.7 Housing, Lower ................................... 1
57D 38649 503 8649.2 Switch, Membrane .............................. 1
57E 34342 503 4342.4 Screw #4-20 ........................................ 3
57F 33580 503 3580.4 Screw #6-32 ........................................ 3
57G 01666 500 1666.0 Cord, Pendant ..................................... 1
57H 38654 503 8654.9 Strip, Magnetic .................................... 1
58 35012 503 5012.9 Screw, #4 x 1/2" Flat Head or
06683 500 6683.8 Rivet, Pop 3/32 ................................... 2
59 51751 905 1751.2 Screw, Drive ........................................ 4
60 38868 503 8868.1 Nameplate ........................................... 1
71 38221 503 8221.7 Support Weldment, Roller .................. 1
72 00528 500 0528.6 Support Weldment, 1-1/2" .................. 1
73 00601 500 0601.0 Support Weldment, 2" ......................... 1
74 38225 503 8225.0 Arm Weldment, Adjustment ................ 1
75 00543 500 0543.0 Plate, 1-1/2" Outer Roller ................... 1
76 00604 500 0604.5 Plate, 2" Outer Roller .......................... 1
77 38254 503 8254.3 Rol, 1-1/2............................................. 2
78 38264 503 8264.0 Ball, 1-1/2 ............................................ 2
79 38255 503 8255.1 Rol, 2 ................................................... 2
80 38263 503 8263.2 Ball, 2 .................................................. 2
81 38262 503 8262.4 Spacer, 2 Roller .................................. 1
82 00599 500 0599.5 Roller Unit, 2" ...................................... 1
83 00493 500 0493.0 Shaft, 2" Rear Roller ........................... 1
84 38252 503 8252.7 Roller, 1-1/2 I.M.C............................... 1
85 38253 503 8253.5 Roller, 2 Tail ........................................ 1
86 38260 503 8260.8 Shaft, 1-1/2 Pivot Roller...................... 1
87 32027 503 2027.0 Sleeve, 1-1/2 ....................................... 1
88 31728 503 1728.8 Shaft, 2 Pivot....................................... 1
89 38151 503 8151.2 Sleeve, 2 ............................................. 1
90 23258 502 3258.4 Grip...................................................... 1
91 38256 503 8256.0 Shaft, Eccentric ................................... 1
92 38251 503 8251.9 Sleeve, Adaptor .................................. 1
93 50540 905 0540.9 Screw, 7/16-14 x 1.00 Hex Hd ........... 3
94 00860 500 0860.9 Shaft, 1-1/2" Support .......................... 1
95 54819 905 4819.1 Retaining Ring #5100-87 .................... 2
96 54242 905 4242.8 Screw, Cap 1/4-20 x .37 Btn Hd ......... 3
