Greenlee Textron / Subsidiary of Textron Inc.
25
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
855 Smart Bender™
Special Bending Information Chart (cont’d)
1/2" IMC, Rigid and 40 Mil PVC-Coated Rigid
Y 15 3.03 10.76 18.48 26.21 33.94 41.67 53.26 64.85 88.03 134.39
L1 15 7.72 15.45 23.18 30.90 38.63 46.36 57.95 69.54 92.72 139.09
L2 15 8.87 16.59 24.32 32.05 39.78 47.50 59.10 70.69 93.87 140.23
Z 15 11.12 18.58 26.05 33.51 40.97 48.44 59.63 70.83 93.22 138.01
MINIMUM H = 0.95
Y 22.5 .77 5.98 11.21 16.44 21.66 26.89 34.73 42.57 58.25 89.60
L1 22.5 5.20 10.43 15.66 20.88 26.11 31.34 39.17 47.01 62.69 94.05
L2 22.5 6.92 12.15 17.38 22.60 27.83 33.06 40.89 48.73 64.41 95.77
Z 22.5 9.07 13.90 18.73 23.56 28.38 33.21 40.46 47.70 62.18 91.15
MINIMUM H = 1.62
Y 30 3.49 7.49 11.49 15.49 19.49 25.49 31.49 43.49 67.49
L1 30 7.95 11.95 15.95 19.95 23.95 29.95 35.95 47.95 71.95
L2 30 10.24 14.24 18.24 22.24 26.24 32.24 38.24 50.24 74.24
Z 30 11.78 15.24 18.70 22.17 25.63 30.83 36.02 46.42 67.20
MINIMUM H = 2.42
Y 45 3.59 6.41 9.23 12.06 16.30 20.55 29.03 46.00
L1 45 8.30 11.13 13.95 16.78 21.02 25.27 33.75 50.72
L2 45 11.74 14.57 17.39 20.22 24.46 28.71 37.19 54.16
Z 45 12.13 14.13 16.13 18.13 21.13 24.13 30.13 42.13
MINIMUM H = 4.33
Y 60 1.42 3.73 6.04 8.34 11.81 15.27 22.20 36.06
L1 60 8.77 11.08 13.39 16.85 20.31 27.24 41.10
L2 60 13.35 15.66 17.97 21.44 24.90 31.83 45.69
Z 60 12.18 13.33 14.49 16.22 17.95 21.41 28.34
MINIMUM H = 6.55
Y 90 .71 2.71 4.71 7.71 10.71 16.70 28.70
L1 90 10.12 13.12 16.12 22.12 34.12
L2 90 17.00 20.00 23.00 29.00 41.00
Z 90 11.26 11.26 11.26 11.26 11.26
MINIMUM H = 11.26
3/4" IMC, Rigid and 40 Mil PVC-Coated Rigid
Y 15 1.86 9.58 17.31 25.04 32.77 40.49 52.08 63.68 86.86 133.22
L1 15 7.72 15.45 23.17 30.90 38.63 46.36 57.95 69.54 92.72 139.08
L2 15 9.19 16.91 24.64 32.37 40.09 47.82 59.41 71.00 94.19 140.55
Z 15 12.06 19.53 26.89 34.46 41.92 49.38 60.58 71.78 94.17 138.95
MINIMUM H = 1.19
Y 22.5 4.85 10.08 15.31 20.53 25.76 33.60 41.44 57.12 88.47
L1 22.5 10.42 15.65 20.88 26.10 31.33 39.17 47.01 62.69 94.04
L2 22.5 12.62 17.85 23.08 28.30 33.53 41.37 49.21 64.89 96.24
Z 22.5 15.01 19.84 24.67 29.49 34.32 41.57 48.81 63.29 92.26
MINIMUM H = 2.05
Y 30 2.33 6.33 10.33 14.33 18.33 24.33 30.33 42.33 66.33
L1 30 7.93 11.93 15.93 19.93 23.93 29.93 35.93 47.93 71.93
L2 30 10.86 14.86 18.86 22.86 26.86 32.86 38.86 50.86 74.86
Z 30 13.05 16.52 19.98 23.45 26.91 32.11 37.30 47.70 68.48
MINIMUM H = 3.06
Y 45 2.31 5.13 7.96 10.79 15.03 19.28 27.76 44.73
L1 45 8.24 11.07 13.90 16.73 20.97 25.21 33.70 50.67
L2 45 12.64 15.47 18.30 21.13 25.37 29.61 38.10 55.07
Z 45 13.76 15.76 17.76 19.76 22.76 25.76 31.76 43.76
MINIMUM H = 5.49
Y 60 2.28 4.59 6.90 10.36 13.83 20.75 34.61
L1 60 10.94 13.25 16.72 20.18 27.11 40.97
L2 60 16.81 19.12 22.58 26.05 32.98 46.83
Z 60 15.36 16.52 18.25 19.88 23.45 30.38
MINIMUM H = 8.31
Y 90 .76 2.76 5.76 8.76 14.76 26.76
L1 90 12.60 15.60 21.60 33.60
L2 90 21.39 24.39 30.39 42.39
Z 90 14.33 14.33 14.33 14.33
MINIMUM H = 14.33
DIM ANGLE 2" 4" 6" 8" 10" 12" 15" 18" 24" 36"
