Greenlee 855 - Parts List for Shoe and Roller Units

Greenlee Textron / Subsidiary of Textron Inc.
43
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
855 Smart Bender™
1/2" to 1-1/4" Side, 1-1/2" to 2" Side,
and 1-1/2" to 2" Roller Support Unit Parts List
3 38217 503 8217.9 Guard Weldment, Top Chain .............. 1
5 38232 503 8232.2 Guard Weldment, Motor ..................... 1
7 38199 503 8199.7 Sppt Wldt, 1/2" to 1-1/4" RLR ............. 1
19 52397 905 2397.0 Pin, 1/2" to 1-1/4" Sprt Pvt .................. 1
23 51655 905 1655.9 Screw, #10-16 .50 Hex Hd ............... 31
26 52501 905 2501.9 Ring, Rtng Truarc #5100-287 ............. 2
43 38780 503 8780.4 Shoe Unit, 1/2" to 1-1/4" ..................... 1
44 38148 503 8148.2 Shoe Unit, 1-1/2" to 2" ........................ 1
71 38221 503 8221.7 Support Weldment, Roller .................. 1
72 00528 500 0528.6 Support Weldment, 1-1/2" .................. 1
73 00601 500 0601.0 Support Weldment, 2" ......................... 1
74 38225 503 8225.0 Arm Weldment, Adjustment ................ 1
75 00543 500 0543.0 Plate, 1-1/2" Outer Roller ................... 1
76 00604 500 0604.5 Plate, 2" Outer Roller .......................... 1
77 38254 503 8254.3 Split Rollers, 1-1/2 .............................. 2
78 38264 503 8264.0 Ball, 1-1/2 ............................................ 2
79 38255 503 8255.1 Split Rollers, 2 ..................................... 2
80 38263 503 8263.2 Ball, 2 .................................................. 2
81 38262 503 8262.4 Spacer, 2 Roller .................................. 1
82 00599 500 0599.5 Roller Unit, 2" ...................................... 1
83 00493 500 0493.0 Shaft, 2" Rear Roller ........................... 1
84 38252 503 8252.7 Roller, 1-1/2 IMC ................................. 1
85 38253 503 8253.5 Roller, 2 Tail ........................................ 1
86 38260 503 8260.8 Shaft, 1-1/2 Pivot Roller...................... 1
87 32027 503 2027.0 Sleeve, 1-1/2 ....................................... 1
88 31728 503 1728.8 Shaft, 2 Pivot....................................... 1
89 38151 503 8151.2 Sleeve, 2 ............................................. 1
90 23258 502 3258.4 Grip...................................................... 1
91 38256 503 8256.0 Shaft, Eccentric ................................... 1
92 38251 503 8251.9 Sleeve, Adapter .................................. 1
93 50540 905 0540.9 Screw, 7/16-14 x 1.00 Hex Hd ........... 3
94 00860 500 0860.9 Shaft, 1-1/2" Support .......................... 1
95 54819 905 4819.1 Retaining Ring #5100-87 .................... 2
96 54242 905 4242.8 Screw, Cap 1/4-20 x .37 Btn Hd ......... 3
97 50224 905 0224.8 Screw, 5/16-18 x 1.00 Skt Hd............. 1
98 50881 905 0881.5 Screw, 1/4-28 x .25 Set ...................... 2
99 53018 905 3918.4 Washer, 1.00 x 1.37 x .03 Shim ......... 1
100 54248 905 4248.7 Washer, Belleville 1.362 x .803 .......... 2
101 39440 503 9440.1 Washer, .62 x 2.00 x .06 Flat ............. 1
104 54243 905 4243.6 Spring, Extension .75 x 3.50 .............. 2
105 54252 905 4252.5 Clamp, Loop Type............................... 1
115 38592 503 8592.5 Guide, Spring ...................................... 1
116 51130 905 1130.1 O-Ring, 1.50 x 1.62 x .062.................. 2
117 51537 905 1537.4 O-Ring, 1.75 x 1.87 x .062.................. 2
118 38657 503 8657.3 Shaft, 2 Middle Roller ......................... 1
119 52644 905 2644.9 Washer, 1/32 Shim ............................. 1
150 52645 905 2645.7 Washer, 1/16 Shim ............................. 1
151 53216 905 3216.3 Retaining Ring #5100-62 .................... 1
204 53390 905 3390.9 Wheel .................................................. 2
205 38166 503 8166.0 Axle, Long ........................................... 1
206 51528 905 1528.5 Ring, Retaining #5160-75 ................... 2
207 54237 905 4237.1 Screw, Flange 3/8-16 x 1.00 Hex ..... 16
213 38464 503 8464.3 Pad Weldment, Jack Bolt ................... 4
215 54276 905 4276.2 Caster, 8 Swivel .................................. 2
221 31710 503 1710.5 1/2" to 1-1/4" IMC, Rigid Hook ........... 1
223 31712 503 1712.1 1/2" to 1-1/4" EMT Hook ..................... 1
224 52479 905 2479.9 Drive Bolt, 1/2-13 x .62
Socket Head Cap Screw..................... 6
225 51088 905 1088.7 1/2" to 1-1/4" Hook Bolts,
3/8-16 x 1-1/4
Socket Head Cap Screw..................... 8
226 53396 905 3396.8 1-1/2, 2" Hook Shoulder Bolts,
3/4 x 1-1/2 ........................................... 6
228 31716 503 1716.4 1-1/2, 2" EMT Hook ............................ 1
229 38779 503 8779.0 1-1/2, 2" IMC and Rigid Hook ............. 1
232 54880 905 4880.9 Wrench, 5/16" Hex T-handle .............. 1
UPC No.
Key 78-3310- Part No. Description Qty.
UPC No.
Key 78-3310- Part No. Description Qty.
