Grizzly G0458Z User Manual

-44-
Model G0458Z (Mfd. Since 7/19)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0458Z001 SIDE COVER 57 P0458Z057 CAP SCREW M6-1 X 12
2 P0458Z002 PHLP HD SCR M5-.8 X 8 58 P0458Z058 CAP SCREW M6-1 X 15
3 P0458Z003 FLAT WASHER 5MM 59 P0458Z059 SET SCREW M5-.8 X 5
4 P0458Z004 DRIVE PULLEY 60 P0458Z060 LOCK WASHER 8MM
5 P0458Z005 SET SCREW M6-1 X 10 61 P0458Z061 BALL BEARING 6904ZZ
6 P0458Z006 FIXED COVER 62 P0458Z062 BEARING SEAT
7 P0458Z007 CAP SCREW M5-.8 X 16 63 P0458Z063 SPROCKET
8 P0458Z008 CAP SCREW M8-1.25 X 16 64 P0458Z064 ELEVATION SCREW CAP
9 P0458Z009 SIDE CABINET 65 P0458Z065 GEAR 65T
10 P0458Z010 ELECTRICAL BOX COVER 66 P0458Z066 BRACKET
11 P0458Z011 CIRCUIT BREAKER L1 SERIES 25A 67 P0458Z067 ELEVATION SCREW ROD
12 P0458Z012 PADDLE SAFETY SWITCH KEDU HY18-4P 68 P0458Z068 LOWER CASTING
13 P0458Z013 POTENTI OMETER W/ DI AL 69 P0458Z069 V-BELT B40
14 P0458Z014 PHLP HD SCR M5-.8 X 15 70 P0458Z070 CAP SCREW M8-1.25 X 12
15 P0458Z015 CIRCUI T BOARD TN40-55 (J SC) 71V2 P0458Z071V2 DRIVE PULLEY V2.07.19
16 P0458Z016 TAP SCREW M3.5 X 8 72 P0458Z072 STRAIN RELIEF TYPE-3 M20-2.5
19 P0458Z019 POINTER 73 P0458Z073 WRENCH 8 X 12 OPEN-ENDS
22 P0458Z022 HEAD CASTI NG 74 P0458Z074 MOTOR 1.5HP 120V 1-PH
23 P0458Z023 TABLE HEIGHT SCALE 74-1 P0458Z074-1 MOTOR FAN COVER
24 P0458Z024 CAP SCREW M6-1 X 12 74-2 P0458Z074-2 MOTOR FAN
25 P0458Z025 TORSION SPRING (LEFT) 74-3 P0458Z074-3 S CAPACITOR 350UF 125V 1-5/16" X 3-1/2"
26 P0458Z026 TORSION SPRING (RI GHT) 74-4 P0458Z074-4 R CAPACITOR 25UF 250V 1-5/8" X 3-1/8"
27 P0458Z027 ROLLER MOUTING PLATE 74-5 P0458Z074-5 J UNCTION BOX
28 P0458Z028 ROLLER 74-6 P0458Z074-6 CONTACT PLATE
29 P0458Z029 PIVOT SHOULDER PIN 74-7 P0458Z074-7 CENTRI FUGAL SWI TCH
30 P0458Z030 CHIP DEFLECTOR PLATE 74-8 P0458Z074-8 BALL BEARING 6204-2RS (FRONT & REAR)
31 P0458Z031 CAP SCREW M6-1 X 10 75 P0458Z075 WORM GEAR
32 P0458Z032 TAP SCREW M5 X 10 76 P0458Z076 EXT RETAINI NG RING 12MM
33 P0458Z033 TOP COVER 77 P0458Z077 SHAFT
34 P0458Z034 HINGE 3" 78 P0458Z078 ROLL PIN 3 X 16
35 P0458Z035 EXT RETAI NI NG RI NG 20MM 79 P0458Z079 HANDWHEEL W/HANDLE TYPE-3 177D X M6-1
36 P0458Z036 FEED ROLLER BRACKET 80 P0458Z080 LOCK WASHER 10MM
37 P0458Z037 BUSHING 81 P0458Z081 HEX BOLT M6-1 X 45
38 P0458Z038 FEED BELT ROLLER 82 P0458Z082 CHAIN 410-132
39 P0458Z039 MOTOR SUPPORT BRACKET 83 P0458Z083 FIXED PLATE
40 P0458Z040 MOTOR MOUNTI NG BRACKET 84 P0458Z084 FLAT WASHER 10MM
42 P0458Z042 FEED MOTOR 1.5HP 110DC 85 P0458Z085 ADJ USTMENT BLOCK
42-1 P0458Z042-1 MOTOR BRUSHES (2-PC SET) 86 P0458Z086 HEX NUT M5-.8
43 P0458Z043 CONVEYOR TABLE 87 P0458Z087 CAP SCREW M6-1 X 35
44 P0458Z044 TABLE GUIDE 88 P0458Z088 ADJ USTMENT ROD
45 P0458Z045 STEEL BAR 89 P0458Z089 CAP SCREW M6-1 X 20
46 P0458Z046 PLATE 90 P0458Z090 HEX NUT M6-1
47 P0458Z047 LOCK COLLAR 16MM 91 P0458Z091 CORD CLAMP
48 P0458Z048 SET SCREW M5-.8 X 8 92 P0458Z092 CAP SCREW M10-1.5 X 25
49 P0458Z049 FEED BELT ROLLER 93 P0458Z093 FLAT WASHER 10MM
50 P0458Z050 HEX BOLT M8-1.25 X 20 94 P0458Z094 SANDING BELT 100-GRIT 3" X 84"
51 P0458Z051 HEX NUT M8-1.25 95 P0458Z095 CONVEYOR BELT
52 P0458Z052 FEED ROLLER BRACKET (REAR) 96 P0458Z096 CAP SCREW M6-1 X 30
54 P0458Z054 BEARING COVER (LEFT) 97 P0458Z097 POWER CORD 14G 3W 72" 5-15P
55 P0458Z055 LEADSCREW FIXED PLATE 98 P0458Z098 FLAT WASHER 12MM
56 P0458Z056 BASE COVER PLATE 99 P0458Z099 FLAT WASHER 8MM
Main Parts List
