Main Parts List (Cont.)
REF PART # DESCRIPTION REF PART # DESCRIPTION
100 P0458Z100 KEY 6 X 6 X 40 132 P0458Z132 COMPRESSION SPRING
101 P0458Z101 STAND LEG 133 P0458Z133 CONNECTION WIRE 1, 14AWG, 100L
102 P0458Z102 CARRIAGE BOLT M8-1.25 X 16 134 P0458Z134 CAP SCREW M6-1 X 25
103 P0458Z103 SHORT BRACKET (BOTTOM) 135 P0458Z135 CAP SCREW M5-.8 X 10
104 P0458Z104 LONG BRACKET (BOTTOM) 136 P0458Z136 WAVY WASHER 40MM
105 P0458Z105 FLANGE NUT M8-1.25 137 P0458Z137 BEARING COVER (RIGHT)
106 P0458Z106 LONG BRACKET (TOP) 138 P0458Z138 EXTENSION SPRING
107 P0458Z107 SHORT BRACKET (TOP) 139 P0458Z139 SPRING RETAINER
108 P0458Z108 CONTROL PANEL PLATE 140 P0458Z140 CONNECTION WIRE 3, 14AWG, 50L
109 P0458Z109 HEX WRENCH 6MM 141 P0458Z141 CAP SCREW M5-.8 X 12
110 P0458Z110 HEX WRENCH 5MM 142 P0458Z142 HEX NUT M3-.5
111 P0458Z111 HEX WRENCH 4MM 143 P0458Z143 SHOULDER SCREW M5-.8 X 30, 6 X 30
112 P0458Z112 INFEED COVER 144 P0458Z144 FLAT WASHER 5MM
113 P0458Z113 SPACER BLOCK 145 P0458Z145 LOCK WASHER 5MM
114 P0458Z114 BUSHI NG 146 P0458Z146 HEX NUT M5-. 8
116 P0458Z116 SPROCKET 147 P0458Z147 CAP SCREW M6-1 X 20
117 P0458Z117 HEX NUT M5-. 8 148 P0458Z148 FLAT WASHER 6MM
118 P0458Z118 FLAT WASHER 5 X 14 OD X 0.8 T 149 P0458Z149 SET SCREW M8-1.25 X 20
119 P0458Z119 SPADE TERMINAL (F) 150 P0458Z150 HEX BOLT M5-.8 X 25
120 P0458Z120 CAP SCREW M5-.8 X 8 151 P0458Z151 CAP SCREW M8-1.25 X 16
121 P0458Z121 FLAT WASHER 5MM 152 P0458Z152 SET SCREW M8-1.25 X 10
122 P0458Z122 FLAT WASHER 8MM 153 P0458Z153 FLAT WASHER 3MM
123 P0458Z123 BALL BEARING 6205ZZ 154 P0458Z154 COLLAR
124 P0458Z124 EXT RETAI NING RI NG 25MM 155 P0458Z155 SET SCREW M6-1 X 6
125 P0458Z125 SANDING BELT CLAMP BRACKET (RIGHT) 156 P0458Z156 FLAT WASHER 5MM
126 P0458Z126 SANDING BELT CLAMP BRACKET (LEFT) 160 P0458Z160 CAP SCREW M6-1 X 16
127 P0458Z127 HOLLOW HANDLE 26 X 106, 9 161 P0458Z161 KEY 4 X 4 X 8
128 P0458Z128 SHOULDER SCREW M8-1.25 X 16, 10 X 116 162 P0458Z162 SET SCREW M4-.7 X 8
129 P0458Z129 BELT DRUM 163 P0458Z163 RUBBER CUSHI ON
130 P0458Z130 CONNECTION WIRE 2, 14AWG, 100L 164 P0458Z164 BUSHI NG
131 P0458Z131 BELT LOCKING BLOCK 165 P0458Z165 PHLP HD SCR M3-.5 X 16
