Grizzly T33903 User Manual

-54-
Model T33903/T33904 (Mfd. Since 07/23)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PT33904001 V-BELT A-787 56 PT33904056 QUICK-RELEASE BUTTON
2 PT33904002 MOTOR PULLEY 57 PT33904057 DEPTH SCALE
3 PT33904003 SET SCREW M8-1.25 X 10 58 PT33904058 THREADED DEPTH ROD
4 PT33904004 BALL BEARING 6202-2RS 59 PT33904059 FLAT HD SCR M6-1 X 12
5 PT33904005 IDLER PULLEY 60 PT33904060 DEPTH STOP BRACKET
6 PT33904006 CRANKSHAFT 61 PT33904061 DEPTH COLLAR
7 PT33904007 BELT COVER 62 PT33904062 HEX NUT M12-1.75
8 PT33904008 KNOB BOLT M5-.8 X 8, D20, ROUND KD 63 PT33904063 HEX NUT M6-1
9 PT33904009 I NT TOOTH WASHER 5MM 64 PT33904064 CAP SCREW M6-1 X 45
10 PT33904010 ACORN NUT M5-. 8 65 PT33904065 SET SCREW M6-1 X 10
11 PT33904011 SET SCREW M8-1.25 X 16 66 PT33904066 EXT RETAINI NG RI NG 25MM
12 PT33904012 V-BELT A-686 67 PT33904067 SPACER 62 X 80 X 2.5MM RUBBER
13 PT33904013 SPINDLE PULLEY 68 PT33904068 BALL BEARING 6005-2RS
14 PT33904014 SPINDLE SLEEVE 69 PT33904069 QUILL
15 PT33904015 KEY 10 X 5 X 35 70 PT33904070 DRI FT KEY
16 PT33904016 BALL BEARING 6007-2RS 71 PT33904071 THRUST BEARI NG 51107
17 PT33904017 SPACER 56 X 62 X 10MM 72 PT33904072 BALL BEARING 6007-2RS
18 PT33904018 EXT RETAI NI NG RI NG 35MM 73 PT33904073 SPINDLE MT#4
19 PT33904019 HEX NUT M5-. 8 74 PT33904074 DRI LL CHUCK ARBOR MT#4 X J T3
20 PT33904020 CORD CLAMP LARGE 75 PT33904075 DRILL CHUCK JT3 X 1/8-5/8
21 PT33904021 FLAT WASHER 5MM 76 PT33904076 DRILL CHUCK KEY 5/16" SE 12T SD-11/16"
22 PT33904022 PHLP HD SCR M5-.8 X 16 77 PT33904077 CHUCK GUARD ASSEMBLY
23 PT33904023 TAP SCREW M4.2 X 12 77-1 PT33904077-1 HEX NUT M4-. 7
24 PT33904024 CORD CLAMP SMALL 77-2 PT33904077-2 CHUCK GUARD COLLAR
25 PT33904025 HEX BOLT M8-1.25 X 12 77-3 PT33904077-3 HEX NUT M6-1
26 PT33904026 FLAT WASHER 8MM 77-4 PT33904077-4 PHLP HD SCR M4-.7 X 30
27 PT33904027 BUSHING RUBBER 77-5 PT33904077-5 TAP SCREW M2.6 X 6
28 PT33904028 FLAT WASHER 9 X 18 X 2.5MM RUBBER 77-6 PT33904077-6 HINGE BRACKET
29 PT33904029 FOLDING HANDLE M10-1.5 X 25 DOG-PT, 35L 77-7 PT33904077-7 EXTENSION SPRING 0.8 X 6.5 X 30
30 PT33904030 BELT TENSION LEVER 77-8 PT33904077-8 HEX BOLT M5-.8 X 16
31 PT33904031 EXT RETAI NI NG RI NG 15MM 77-9 PT33904077-9 WI NG NUT M5-.8
32 PT33904032 SET SCREW M10-1.5 X 12 77-10 PT33904077-10 GUARD LOWER
33 PT33904033 HEADSTOCK 77-11 PT33904077-11 GUARD UPPER
34 PT33904034 SET SCREW M10-1.5 X 12 77-12 PT33904077-12 PHLP HD SCR M4-.7 X 35
35 PT33904035 STUD-SE M4-.7 X 8, 13.5 SLOTTED 77-13 PT33904077-13 HEX BOLT M6-1 X 20
36 PT33904036 RETURN SPRING ASSEMBLY 77-14 PT33904077-14 LOCK NUT M4-. 7
36-1 PT33904036-1 RETURN SPRI NG COVER 78 PT33904078 PIVOT PIN 7 X 12, 10.5 X 19MM
36-2 PT33904036-2 FLAT COIL SPRING 79 PT33904079 BELT TENSION BLOCK
37 PT33904037 THUMB NUT M6-1 KD 80 PT33904080 SET SCREW M8-1.25 X 10
38 PT33904038 FLAT WASHER 6MM 81 PT33904081 SLIDE BAR LEFT
39 PT33904039 LOCK WASHER 6MM 82 PT33904082 SLIDE BAR RIGHT
40 PT33904040 CAP SCREW M6-1 X 16 83 PT33904083 HEX BOLT M8-1.25 X 25
41 PT33904041 EXT TOOTH WASHER 5MM 84 PT33904084 FLAT WASHER 8MM
42 PT33904042 FLAT WASHER 5MM 85 PT33904085 MOTOR MOUNT
43 PT33904043 LOCK WASHER 5MM 86 PT33904086 HEX NUT M8-1. 25
44 PT33904044 PHLP HD SCR M5-.8 X 8 87 PT33904087 HEX BOLT M8-1.25 X 30
45 PT33904045 TRANSFORMER HOPESTAR LED-5V700 5V 88 PT33904088 FLAT WASHER 12MM
46 PT33904046 PHLP HD SCR M4-.7 X 8 89 PT33904089 LOCK WASHER 12MM
47 PT33904047 LI GHT ON/ OFF SWI TCH DKLD AN-18 RED 90 PT33904090 HEX NUT M12-1.75
48 PT33904048 LASER ON/OFF SWITCH DKLD AN-18 BLACK 91 PT33904091 KEY 6 X 6 X 40
49 PT33904049 SWI TCH BOX 92 PT33904092 HEX NUT M8-1. 25
50 PT33904050 CAP SCREW M6-1 X 12 93 PT33904093 FLAT WASHER 8MM
51 PT33904051 SWI TCH PLATE 94 PT33904094 MOTOR 1-1/4HP 120V 1-PH
52 PT33904052 ON/ OFF SWI TCH DKLD AN17 94-1 PT33904094-1 MOTOR FAN COVER
53 PT33904053 TAP SCREW M3.5 X 10 94-2 PT33904094-2 MOTOR FAN
54 PT33904054 DEPTH STOP NUT M12-1.75 94-3 PT33904094-3 CENTRI FUGAL SWITCH 3/ 4 1700
55 PT33904055 COMPRESSION SPRING 1.2 X 14 X 11.5 94-4 PT33904094-4 CONTACT PLATE 19 X 26MM EXT
T33904 Main Parts List
