Accessories for small dosing pumps up to 60 l/h
50
Accessories for dosing pumps
8
Hose-to-hose and hose-to-pipe adapters
Technical data
T-pieces
Technical data
Type Description
Connections Material
Product number
Side 1 Side 2
Body and
connections
Gaskets
TM04 8302 0411
Valve body with two
external threads G 5/8"
For hoses 4/6 mm, 6/9 mm, 6/12 mm,
9/12 mm
PP FKM / EPDM 95730367
PVC
FKM / EPDM 95730368
PTFE 95730369
PVDF
FKM / EPDM 95730370
PTFE 95730371
Without
PP FKM / EPDM 95730356
PVC
FKM / EPDM 95730357
PTFE 95730358
PVDF
FKM / EPDM 95730359
PTFE 95730360
Without Threaded Rp 1/4 Stainless steel PTFE 95730361
TM04 8360 0711
Pipe cementing end on
one side, external thread
G 5/8" on the other side
For hoses 4/6 mm,
6/9 mm, 6/12 mm,
9/12 mm
Internal ∅12 mm PVC
FKM / EPDM 95730378
PTFE 95730379
Without Internal ∅12 mm PVC
FKM / EPDM 95730365
PTFE 95730366
TM04 8303 0411
Pipe welding end on one
side, external thread G
5/8" on the other side
For hoses 4/6 mm,
6/9 mm, 6/12 mm,
9/12 mm
External ∅16 mm
PP FKM / EPDM 95730377
PVDF
FKM / EPDM 95730380
PTFE 95730381
Without External ∅16 mm
PP FKM / EPDM 95730362
PVDF
FKM / EPDM 95730363
PTFE 95730364
Type Description
Connections Material
Product number
Bottom Top Side
Body and
connections
Gaskets
TM04 8304 0411
Three external
threads G 5/8"
For hoses 4/6 mm, 6/9 mm, 6/12 mm,
9/12 mm
PP FKM / EPDM 95730387
PVC
FKM / EPDM 95730388
PTFE 95730389
PVDF
FKM / EPDM 95730390
PTFE 95730391
- Without -
PP FKM / EPDM 95730346
PVC
FKM / EPDM 95730347
PTFE 95730348
PVDF
FKM / EPDM 95730349
PTFE 95730350
TM04 8305 0411
Two male threads G
5/8", one internal
connection with union
nut
Union nut
G 5/8"
Without
For hoses
4/6 mm,
6/9 mm,
6/12 mm,
9/12 mm
PP FKM / EPDM 95730397
PVC
FKM / EPDM 95730398
PTFE 95730399
PVDF
FKM / EPDM 95730400
PTFE 95730401
Without
PP FKM / EPDM 95730351
PVC
FKM / EPDM 95730352
PTFE 95730353
PVDF
FKM / EPDM 95730354
PTFE 95730355
