Accessories for small dosing pumps up to 60 l/h
51
Accessories for dosing pumps
8
Dosing tanks
Square tank, 100 litres
The closed, square tank has a screw cap and a
mounting platform for one pump or two pumps in
parallel.
The pump mounting platform is higher than the screw
cap to protect pumps and connections when filling
chemicals into the tank.
• Tank material: MDPE
• Weight: 15 kg
• Wall thickness: 4 mm
• Liquid temperature: -20 °C to +45 °C.
SMART Digital S pumps can be fitted directly on the
mounting platform by means of brass inserts moulded
into the platform. For other pumps a bracket is
required.
The square tank is prepared for a G 3/4" drain valve.
When using a rigid suction lance in the tank, choose
the counter nut for fixing (see page 41).
Fig. 48 Square tank
Dimensions
Fig. 49 Square tank, dimensions
Order data
TM04 8307 0411
TM04 8308 0411
Tank volume
[l]
Product number
100 96489271
Ø152
540
670
500
500
98
98
98
137
192
M5
