Grundfos DME User Manual

5
1.2 Type key
(Cannot be used for pump configuration.)
Code Example DME 2 - 18 A - PP/ E/ C - F - 3 1 RR B
Grundfos dosing pump
Pump range DME
Maximum pressure [bar]
A
AR
AP
AG
Control variant
Standard
Standard + alarm relay
Standard + Profibus
Standard + GENIbus
PP
PV
SS
Dosing head material
Polypropylene
PVDF
Stainless steel AISI 316
E
V
T
Gasket material
EPDM
FKM
PTFE
C
SS
T
Valve ball material
Ceramics
Stainless steel AISI 316
PTFE
F
S
Control panel
Front-fitted
Side-fitted
1
Voltage
1 x 120 V, 60 Hz
1
2
Valves
Standard valve
Spring-loaded valve
T
R
S
V
Y
X
Connection, suction/discharge
Tubing 0.125"/0.25"
Tubing 0.25"/0.375"
Tubing 0.375"/0.5"
Threaded 1/4" NPT*
Threaded 3/8" NPT*
Threaded 1/2" NPT*
* On stainless-steel pumps only
B
Power plug
USA, Canada (120 V)
Grundfos.bk Page 5 Wednesday, May 21, 2008 11:21 AM
