GSi Chain Disk APCD-500 User Manual

12
APCD-500, rev10
APCD-500
Refer to section 5.6 to set the bin
auger parameters
NOTE: The whole Chain Disk stops
running when an alarm is active!
Sec. 4.4.3
& Graph D
Sec. 4.4.5
& Graph G
Independent
Chain Disk
System
Cascaded
Chain Disk
System
Common
Bin Auger
Individual
Bin Augers
Type of
Chain Disk
System
Continuous
Feeding
Timed
Feeding
Continuous
Feeding
Timed
Feeding
Continuous
Feeding
Timed
Feeding
With
proximity
sensor
Without
proximity
sensor
Without
proximity
sensor
With
proximity
sensor
With
proximity
sensor
Without
proximity
sensor
Sec. 4.4.4
& Graph E
Sec. 4.4.4
& Graph F
Sec. 4.4.6
& Graph H
Sec. 4.4.6
& Graph I
Sec. 4.4.1,
& Graph A
Sec. 4.4.2,
&
Graph B
Sec. 4.4.2,
& Graph C
Filling Process According to the
System Setup:
The filling process of Chain Disk System de-
pends on your particular system setup. Locate
your particular application setup on the hierarchy
tree below and then refer to the proper section of
the manual to get explanations about the filling
process of the chosen option.
Possible Chain Disk Setup
