5.7.5. Toggle Switch
A toggle switch can be connected to the main
board. This switch allows stopping the drive
unit of the master Chain Disk System and
stopping bin augers manually. If the toggle
switch is turned off for 30 consecutive sec-
onds, the Chain Disk is Not Running alarm will
be activated. Refer to the wiring diagram
enclosed with this manual to connect the
toggle switch.
The toggle switch does not cut the
power lines to the chain disk control-
ler. Shut off the circuit breaker for
servicing and maintenance.
5.7.6. Test Mode
The test mode allows simulating the amper-
age draw of all drive units in order to verify
the controller’s performances.
1. Use the menu select buttons to select the
MANUAL MODE menu.
2. Press the down-arrow key to select the
amperage draw display of the drive unit of
the master Chain Disk System or of a slave
Chain Disk System.
3. Press the down-arrow key to select the
amperage draw of the selected drive unit.
4. Press MODIFY then use the arrow keys to
set the simulated current consumption. Press
MODIFY to validate. * The answer is validated
after 8 seconds.
Do not forget to exit from the test
mode when tests are completed.
