GSi Chain Disk APCD-500 User Manual

37
APCD-500, rev10
APCD-500
5.7. Manual & Test Modes
The manual mode allows activating manually
the actuators, air valves and drive units.
5.7.1. Manual Filling of the Chain
Disk Systems
It is possible to fill some Chain Disk Systems
without waiting for a feed cycle to start.
When this manual start-up is performed, the
Manual Mode pilot light turns on and the
controllers activates the proper outputs in
order to fill up the required Chain Disk
System(s) (see the different filling methods
in section 4.5.2). The manual filling process
ends when the Chain Disk System is full.
If the user manually adds feed to
a Chain Disk System while a feed
cycle is ongoing, the ongoing cycle
will be bypassed and replaced by the manual
filling process. When the controller returns to
the automatic mode, it will not resume the
previous cycle but will wait for the next Dump
Time (if applicable). A manual dump can also
be performed (see next section). Do not forget
to exit from the manual mode when the manual
filling process is completed.
1. Use the menu select buttons to select the
MANUAL MODE menu. *A password may be
required to access this menu (see sec. 5.6).
2. Before enabling the manual filling, select
which Chain Disk System must be filled:
press the down-arrow key to select the
“Manual Start” parameter.
Manual Start
Mastr
3. Press MODIFY then use the arrow keys to
select the Chain Disk System that needs to
be filled manually (Master Chain Disk System,
All Chain Disk Systems or slave 1-7 Chain
Disk Systems). Press MODIFY once again to
validate. When the desired Chain Disk Sys-
tem is selected, activate the manual mode as
shown in section 5.7.2.
5.7.2. Manual Start / Stop
You can choose to start filling a Chain Disk
System or to stop it manually (as explained
in previous section).
1. Use the menu select buttons to select the
MANUAL MODE menu.* A password may be
required to access this menu (see sec. 5.6).
2. The manual mode status is displayed on
screen.
Feed cycles
Mode Auto
3. Press MODIFY then use the arrow keys
to select the desired status: select “Start”
to enable the manual mode; select “Stop” to
stop the Chain Disk system; select “A u t o” to
return to the automatic control mode.
