38
APCD-500, rev10
APCD-500
5.7.3. Bypassing a Chain Disk
System
If required, the controller can bypass a Chain
Disk System (slave or Master Chain Disk
System).
If a bypassed slave Chain Disk
System shares a common bin auger
with other Chain Disk Systems, the
bypassed Chain Disk System will
still run during the “Purge Time” at
the beginning of each cycle.
1. Use the menu select buttons to select the
MANUAL MODE menu. *A password may be
required to access this menu (see sec. 5.6).
2. Press the down-arrow key to select the
status menu of the desired Chain Disk Sys-
tem. * This parameter is available if at least 1 slave
Chain Disk System is enabled.
APCD-500 Master
Status Auto/Bypas
APCD-500-S #1
Status Auto/Bypas
3. Press MODIFY then use the arrow keys
to select the desired status (Auto /Bypass).
Press MODIFY again to validate.
5.7.4. Manual Dump
The actuator/air valve can only be activated
manually when no drive unit is running. The
Manual Mode pilot light flashes while an ac-
tuator or air valve is controlled manually.
1. Use the menu select buttons to select the
MANUAL MODE menu.
Press the down-arrow key to select the
manual mode status of the actuator. * This
parameter is available if the actuator is enabled
(see sec. 5.6).
Actuator
Mode: Auto
2. Press MODIFY then use the arrow keys to
select the desired status (Auto /Open /Stop/
Close). Press MODIFY again to validate. * The
answer is validated after 8 seconds.
3. Press the down-arrow key once. The
manual mode status of the air valve is dis-
played. * This parameter is available if the air valve
is enabled (see sec.5.6).
4. Press MODIFY then use the arrow keys to
select the proper status (Auto/Open/ Close).
Press MODIFY again to validate.* The answer
is validated after 8 seconds.
