APCD-500, rev10
APCD-500
(MA) Purge time (MA) Run time
(MA) Auger delay
(SL) Purge time (SL) Run time
OFF ON OFF
ON OFF
ON OFF ON OFF
A feed cycle starts
(Cycle Time is reached)
Time
APCD-500
Parameters
Mstr ChainD
Status
Slave ChainD
Status
Bin Auger
Status
Purge Cycle Master Chain Disk
System being filled
Slave Chain Disk
Systems being filled
GRAPH F
Chain Disk Setup : Independent Chain Disk Systems
Bin Auger Setup : Common auger
Feed Distribution Mode : Timer
Proximity sensor? : No, a Run Time is used to stop the Chain Disk System
