GSi DMC Design III Series User Manual

6. Parts List
PNEG-1156ETL Design III Series Grain Stir-Ator CSA 59
Design III Stir-Ator Switch Boxes and Suspension Parts List (Continued)
Ref # Part # Description Double Auger Triple Auger
50 105A0051 Center Suspension Tee Bar (Triple) 0 1
51 105A0052 Center Suspension Cross Bar Tube (Triple) 0 1
53 106A077 Suspension Hook (Triple) 0 3
54
106A075-2400 Center Suspension Chain (Triple) 2100-2400 0 3
106A075-3000 Center Suspension Chain (Triple) 2401-3000 0 3
106A075-3900 Center Suspension Chain (Triple) 3001-3900 0 3
106A075-4800 Center Suspension Chain (Triple) 3901-4800 0 3
86 106A068 “S” Hook (Special) A/R A/R
87 106A070 Center Suspension Cross Bar (14' through 15') (Single) 0 0
169 1EL3050
Switch Box to Swivel Wire 12/3 SO (Specify Bin Diameter)
230 Volt, 1 Phase 1-1/2 HP A/R A/R
230 Volt, 1 Phase 2 HP A/R A/R
170 1EL3052
Switch Box to Swivel Wire 14/4 SO (Specify Bin Diameter)
230 Volt, 3 Phase 1-1/2 HP A/R A/R
230 Volt, 3 Phase 2 HP A/R A/R
440 Volt, 3 Phase 1-1/2 HP A/R A/R
440 Volt, 3 Phase 2 HP A/R A/R
171 1EL3047
Switch Box to Swivel Wire 10/3 SO (Specify Bin Diameter)
230 Volt, 1 Phase 2 HP A/R A/R
172 1EL3048
Switch Box to Swivel Wire 10/4 SO (Specify Bin Diameter)
230 Volt, 3 Phase 1-1/2 HP A/R A/R
230 Volt, 3 Phase 2 HP A/R A/R
440 Volt, 3 Phase 2 HP A/R A/R
173 1EL3058
Switch Box to Swivel Wire 8/3 SO (Specify Bin Diameter)
230 Volt, 1 Phase 1-1/2 HP and 2 HP A/R A/R
248 1EL0403 Cord Connector, 3/4'' A/R A/R
255 106E215 Circuit Breaker, Safety Disconnect, 230V, 1 PH, 50A 1 1
258 106E216 Circuit Breaker, Safety Disconnect, 230V, 3 PH, 30A 1 1
259 106E217 Circuit Breaker, Safety Disconnect, 440V, 3 PH, 15A 1 1
260 106E224 Circuit Breaker, Safety Disconnect, 600V, 3 PH, 10A 1 1
304 S-5220 Hex Lock Nut, 5/16'' 6 9
305 S-4663
Hex Lock Nut, 3/8''
Under 36' Only 0 1
36' Bin Diameter and Larger Only 1 2
307 S-1102 Hex Nut, 1/4'' 8 8
308 S-396 Hex Nut, 5/16'' A/R A/R
319 S-420 Spade Bolt, 1/4'' x 2-3/8'' 2 2
331 S-846 Slotted Round Head Machine Screw, 1/4'' x 1'' 2 2
333 S-7643 Slotted Pan Head Machine Screw, 1/4'' x 1/2'' 2 2
336 S-7808 Hex Bolt, 1/4'' x 1-1/4'' 2 2
339 S-861
Hex Bolt, 3/8'' x 2-1/2''
Under 36' Only 0 1
36' Diameter Bin and Larger Only 1 2
345 S-9065 Flange Bolt, 3/8"-16 x 1" ZN Grade 5 0 3
347 2FH0990 Flange Bolt, 5/16"-18 x 1" ZN Grade 5 2 0
371 S-845
Flat washer, 5/16''
27' 1'' to 35' 11'' (Triple) 0 10
36' to 48' (Single-Double-Triple) 10 10
378 3FH0977 Round Cupped Washer, 7/8'' O.D. x 17/64'' I.D. 8 8
388 5FH0082 “S” Hook, #17 2 3
389 5FH0094 Clip 3 3
390 106E214 Breaker Box, Safety Disconnect, 3 PH 1 1
391 106E221 Breaker Box, Safety Disconnect, 1 PH 1 1
392 106E223 Breaker Box, Safety Disconnect, 3 PH, 600V 1 1
