PNEG-1156ETL Design III Series Grain Stir-Ator CSA 19
4. Assembly and Installation
Final Inspection Check List
1. READ THE STIR-ATOR OWNER’S MANUAL BEFORE INSTALLATION. MANY SERVICE
PROBLEMS WILL BE AVOIDED IF THE STIR-ATOR IS PROPERLY INSTALLED.
2. Is there at least 10-1/4" clearance from the center of the track to the lowest part of the roof and
roof braces?
3. Are the track splices correctly installed? Consult the diagrams in the owner’s manual.
4. Is the trolley installed correctly with the arm pointing toward the center of the bin?
5. Are the bolt heads holding the yoke end to the frame on the inside on the frame rails and the cotter
key spread on the pivot tube?
6. Is the suspension bar properly hung, LEVEL, with the end loops down? Is the 1/2" x 2" bolt holding
suspension bar tightly secured? Is the lock nut on tee fitted properly?
7. Is the suspension bar positioned so that the bin “S” hook, to which the shut off chain is attached,
is at a right angle to the switch box chain, as shown in Figure 4F on Page 23. THE POWER CORD
MUST HAVE MORE SLACK THAN THE SHUT OFF CHAIN or the power cord could be torn out of
the switch box if the Design III should malfunction and engage the shut off.
8. Is the frame of the Design III Stir-Ator approximately 1" higher at the center of the bin for each
18' of bin diameter?
9. Are augers 3" (for bins up to 30') or 4" (for bins 33' and larger) off the drying floor at bin wall?
(See Figure 4AU on Page 45.)
10. Were the augers deburred with a file? Were the clamp bolts torqued to 140 foot-pounds? Was the
roll pin installed correctly?
11. Did you note the instruction NOT to weld flighting at the top end of the auger?
12. Are you sure that the electrician connected the black and red - 1 phase wire to the disconnect box or
connect the black, red and white - 3 phase terminals in the disconnect box and the green wire to the
ground? (See Wiring Diagrams on Pages 79-82.) BE SURE BIN IS GROUNDED.
13. Are you keeping a record of the serial number for each owner?
14. Did you make sure that the owner received and signed for his OWNER’S MANUAL and was
instructed that reading and understanding the manual are essential for proper and efficient operation
of the Stir-Ator?
15. Did you install the safety decals on the inside and outside of the walk-in door and the manhole cover?
Installation of Design III Stir-Ator
NOTE: Prior to assembly and installation, consult the bin erection manual or manufacturer for any special
unit hanging or support locations.
1. Before assembling the bin, place the Design III Stir-Ator (without the augers) in the center of the bin
floor. The top ring of the bin is then assembled in the usual way.
