Chapter 8: Power Supply
Table 8-1 Specifications for the electrical load on a quiet dryer (cont'd.)
Dryer
model
Voltage
Motor HP
Full Load
Amps
Maximum amps
with auxiliaries
Minimum
amps
Recommended
service in amps
Branch breaker
in amps
Q116
Q370
1 PH 230V
Load auger
5 26
213 112 350
100
Unload auger
5 26 100
Fan 15 60 100
(2) Auxiliary (2) 7.5
62 *
3 PH 220V
Load auger
5 13.2
145 65.4 200
60
Unload auger
5 13.2 60
Fan 15 39 90
(2) Auxiliary (2) 10
52 *
3 PH 440V
Load auger
5 6.6
78 32.7 150
60
Unload auger
5 6.6 60
Fan 15 19.5 60
(2) Auxiliary (2) 10
26 *
Q118
Q400
3 PH 220V
Load auger
5 13.2
168 86.4 250
60
Unload auger
5 13.2 60
Fan 25 60 90
(2) Auxiliary (2) 10
52 *
3 PH 440V
Load auger
5 6.6
89 43.2 150
60
Unload auger
5 6.6 60
Fan 25 30 60
(2) Auxiliary (2) 10
26 *
Q120
Q460
3 PH 220V
Load auger
7.5 20
215 100 300
90
Unload auger
7.5 20 90
Fan 30 76 90
(2) Auxiliary (2) 15
78 *
3 PH 440V
Load auger
7.5 10
121 58 200
60
Unload auger
7.5 10 60
Fan 30 38 60
(2) Auxiliary (2) 15
39 *
Q122
Q511
3 PH 220V
Load auger
7.5 20
233 116 300
90
Unload auger
7.5 20 90
Fan 30 76 90
(2) Auxiliary (2) 15
78 *
3 PH 440V
Load auger
7.5 10
121 58 200
60
Unload auger
7.5 10 60
Fan 30 38 60
(2) Auxiliary (2) 15
39 *
Q126
Q601
3 PH 220V
Load auger
10 26
271 148 400
90
Unload auger
10 26 90
Fan 40 96 125
(2) Auxiliary (2) 15
78 *
3 PH 440V
Load auger
10 13
140 74 250
60
Unload auger
10 13 60
Fan 40 48 90
(2) Auxiliary (2) 15
39l *
