Chapter 7: Moisture Sampler
Blower Cover Assembly Parts (D04–1016)
Table 7-1 Blower Cover Assembly Part List (D04–1016)
Ref # Part #
Description
Qty.
1
D04-1017-BK Blower Cover Weldment
1
2
D01-2952
Moisture Sampler Blower Housing Bracket
1
3 D01-2959 Blower Mount Short Bracket
1
4
D01-2953 Blower Mount Bracket
1
5 D03-1181
Blower 120V VAC, 50/60 Hz
1
6 D01-2954
Seal Plate, Blower Housing
1
7
D04-1021-BK
10" Vertical Cap Black
1
8 S-6606
Flange Bolt 5/16"-18 x 3/4" ZN Grade 5
15
9 S-3611
Flange Nut 5/16"-18 YDP Grade 2
15
10 S-280
Screw, SDS #10-16 x 5/8" HWH ZN
4
11
D03-1189
Filter, Reusable Rigid Polyester Air, 12" x 12" x 1"
1
12
D02-0028
Clevis Pin 5/16" x 1-3/4" Long Zinc
1
13 S-7375
Cotter Pin, Hairpin 0.93" Wire Diameter
1
54
PNEG–2088 Quiet Portable Dryer
