Chapter 8: Power Supply
Guidelines for Powering Auxiliary Conveyors
Before you can operate the auxiliary conveyors, you must ensure that adequate power is available.
• The auxiliary load and auxiliary unload augers or conveyors can be wired directly to the dryer.
• If an auxiliary motor is larger than recommended, it must be powered from a source outside the
dryer and must use a separate contactor and overload protection device for each motor. However,
you can operate the auxiliaries through the control panel.
• Refer to Specifications for the Electrical Load on a Quiet Dryer, page 63 for the maximum horse-
power and amps that can be wired to the dryer.
Specifications for the Electrical Load on a Quiet Dryer
These charts provide information for you to ensure that the grain dryer and the auxiliary equipment are
supplied with adequate power.
It is recommended that you contact the local power company and have a representative verify the installa-
tion to make sure that the wiring is compatible with their system and adequate power is supplied to the
unit. The only equipment connected to the recommended service amps must be the grain dryer. You must
adhere to all national and local electrical regulations. (Refer to the National Electrical Code Standard
handbook created by the National Fire Protection Association). A qualified electrician must make all elec-
trical wiring installations.
Table 8-1 Specifications for the electrical load on a quiet dryer
Dryer
model
Voltage
Motor HP
Full Load
Amps
Maximum amps
with auxiliaries
Minimum
amps
Recommended
service in amps
Branch breaker
in amps
Q112
Q270
1 PH 230V
Load auger
2 14
178 82 300
60
Unload auger
1.5 8 60
Fan 15 60 100
(2) Auxiliary (2) 7.5
62 *
3 PH 220V
Load auger
2 6.2
113 49 175
50
Unload auger
1.5 5 50
Fan 15 37.8 60
(2) Auxiliary (2) 7.5
40 *
3 PH 440V
Load auger
2 3.1
61.4 24.5 150
60
Unload auger
1.5 2.5 60
Fan 15 18.9 60
(2) Auxiliary (2) 7.5
20 *
Q114
Q320
1 PH 230V
Load auger
5 26
213 112 350
100
Unload auger
5 26 100
Fan 15 60 100
(2) Auxiliary (2) 7.5
62 *
3 PH 220V
Load auger
5 13.2
145 65.4 200
60
Unload auger
5 13.2 60
Fan 15 39 90
(2) Auxiliary (2) 10
52 *
3 PH 440V
Load auger
5 6.6
78 32.7 150
60
Unload auger
5 6.6 60
Fan 15 19.5 60
(2) Auxiliary (2) 10
26 *
