5 Rear Access Ladder
Topics Covered in this Chapter
▪ Installing the Rear Ladder Support Brackets
▪ Installing the Ladder Standoff Brackets to the Rear Ladder Support Brackets
Installing the Rear Ladder Support Brackets
The rear ladder support brackets attach directly to the dryer and support the ladder standoff brackets.
1. Locate the two upper rear ladder bracket installation locations (A) and remove the existing hardware
(B and C).
2. Install one upper rear ladder bracket (A) by aligning it with the bottom bolt in the door frame (B), and
fasten with the previously removed hardware.
3. Install the second upper rear bracket (A) by aligning it with the middle bolt in the gusset plate (C),
and fasten with the previously removed hardware.
4. Align the holes in the lower rear bracket (D) with the holes in the dryer frame and fasten with three
flange bolts (E) and flange nuts (F).
PNEG–2088 Quiet Portable Dryer
35
