5.18. Commissioning Mode
This function was introduced in version 7.46 of the the SmartSetup software. Commissioning Mode is
basically a TESTING mode without needing physical triggers. This is ideal for workshop testing,
before going live.
Examples what you can do:
1. Trigger inputs without physically triggering it. Just click on the input number in the status.
Clicking it will toggle the input state.
2. Change Variable values. Just left click on the variable and a box will pop up where you can
change the variable value.
3. Test / simulate global details. This includes Power ON / OFF, Battery value, Temp on probe A
& B, Analog value.
You can simulate / change the following values:
• Power status ( 1 – ON / 0 – OFF)
• Battery voltage
• Analog value
• Temperatures (probe A & B)
• Date / time
© Polygon Technologies. All rights reserved Page 22
