6.2.6. IO Names Tab
This tab allows the user to rename the inputs and outputs to something that means a little more.
Please Note: These IO Name changes will be stored in the setup that is saved to file, but will
ONLY be stored in the setup that is saved to the GSM Commander if enabled under Settings Tab.
6.2.7. Analog Scaling Tab
This tab allows the user enable the Analog scaling functionality when an Analog Expansion Unit is
connected to the GSM Commander. (See sec 12)
6.2.8. Lock Setup
This tab allows the user to password protect tabs from being accessed as well as the option to save
a new setup to the GSM Commander. This feature comes in handy when an installer doesn't want
the end-user to be able to make changes under certain tabs.
© Polygon Technologies. All rights reserved Page 26
