GSM Commander GC0321 User Manual

1. FEATURES
* Only able to view the current status and history (on Historian package) via Airdrive ( http://www.airdrive.co.za).
** 3G capable GSM Commanders are capable of operating on 3G networks, where 2G is not available. Most countries can
operate on 2G without any issue.
© Polygon Technologies. All rights reserved Page 4
Model On-board Inputs On-board Outputs Max Number of Statements Max number of Messages Max Length of Messages GPRS Enabled 3G Capable** Temp probes Supported Analog Inputs Battery / Power Monitor Extended Analogs DTMF Decoder SIM Card Slots
GC0321 2 2 12/12 32 256 64 127 YES* NO 2 1 YES NO NO Single
2 2 12/12 32 256 64 127 YES* YES 2 1 YES NO NO Single
GC0641 2 2 22/22 64 512 128 127 YES NO 2 1 YES YES YES Single
2 2 22/22 64 512 128 127 YES YES 2 1 YES YES NO Single
GC1281 2 2 32/32 128 512 128 127 YES NO 2 1 YES YES YES Dual
2 2 32/32 128 512 128 127 YES YES 2 1 YES YES NO Dual
Matrix Feature Descriptions
Model The code used to define between the various units functionality and capabilities
On-board Inputs The number of inputs provided on the base unit itself
On-board Outputs The number of outputs provided on the base unit itself
The maximum total number of messages that can be programmed into the unit
GPRS Enabled
The number of temperature probes the base unit can accept
Analog Inputs
Expandable Inputs / Outputs Max number of Phone Numbers
GC0321 3G
GC0641 3G
GC1281 3G
Expandable
Inputs/Outputs
The maximum total number of Inputs/Outputs that can be expanded to by fitting
expansion units
Max Number of
Statements
A measure of the amount of complexity that can be programmed into the unit.
Each statement is of the form IF <ABC happens> THEN <do something>, such as IF
Input 1 goes Active, THEN send “Generator Tripped” to “0831231234”
Max Number of
Phone Numbers
The maximum total number of phone numbers that can be programmed into the
unit
Max Number of
Messages
Max Number of
Statements
The maximum total number of behavior statements that can be programmed into
the unit
If yes, the unit is able to be registered onto the AirDrive Platform which can allow
it to log it's status, log it's events,have remote config and remote output control
via GPRS.
Temp Probes
Supported
The number of analog Inputs available. By default this is a 0-10V analog port. In-
conjunction with a 470 Ohm resistor it can be used for a 4-20mA port as well. See
more information in the Analog port section.
